for Dell'Orto PHVB (Piaggio)

for Dell'Orto PHBN

for Dell'Orto PHVA

for Dell'Orto PHBG

for Dell'Orto PHBL

for Dell'Orto SI 20/24 D/E/G

for Dell'Orto SHB16 F/M/N/L/H

for Dell'Orto SHA 10 - 13

for Dell'Orto FHB A/B 16/24/28

for Dell'Orto SI 20/24 H

universal scooter

K-1000KKThe set contains following articles:float chamber valve set- Keyster = KYV-77015- OEM = 16030-1024float chamber sealing- Keyster = NTMOR-009- OEM = 92055-1128

K-1003SKThe set contains following articles:float chamber sealing- Keyster = K-41- OEM = 13258-44B00float chamber valve set

K-1004SKMThe set contains following articles:float chamber gasket- Keyster = K-41- OEM = 13258-44B00float chamber valve with filter

K-1008YKThe set contains following articles:float chamber sealing- Keyster = NTMOR-020MG- OEM = 3GM-14997-00-00float chamber valve- Keyster = KVN-16R30div. O-rings (see ill.)

K-1010YKMThe set contains following articles:float chamber gasket- Keyster = NTMOR-019MG- OEM = 1HX-14147-00-00float chamber valve set with filter- Keyster = KYV-33L10- OEM = 3CF-14107-10div. O-rings (see ill.)

K-1011KKThe set contains following rtaicles:float chamber gasket- Keyster = NTMOR-008G- OEM = 92055-1426float chamber valve set

K-1020KKMThe set contains following articles:float chamber gasket- Keyster = NTMOR-008G- OEM = 92055-1426float chamber valve set with filter- OEM = 16030-1077

K-1043SKMThe set contains following articles:float chamber gasket- Keyster = NTMOR-021MG- OEM = 13258-33E80float chamber valve set with filter- Keyster = KYV-50015- OEM = 13370-33E80

K-1055KKMThe set contains following articles:float chamber valve set- OEM = 16030-1068float chamber sealing- Keyster = NTMOR-008G- OEM = 92055-1426div. O-rings (see ill.)

K-1482The set contains following articles:4x float chamber gasket- Keyster = NTMOR-005Gcontains float chamber gasketfro following OEM gasket sets:- OEM = 16010-KT7-003- OEM = 16010-MN4-305- OEM = 16010-MN4-0034x float chamber valve set- Keyster = KHV-17026- OEM = 16011-422-004- OEM = 16011-MM4-004- OEM = 16011-MM5-6714x main jet #105- Keyster = KHM-110105- OEM = 99101-GHB-10504x throttle stop jet #35- Keyster = KHS-22B035- OEM = 99103-437-0350

size 200, PHF/ PHM/ PHBH

size 250, PHF/ PHM/ PHBH

size 300, PHF/ PHM/ PHBH

size 350, PHF/ PHM/ PHBH

SHB, VHB, VHBT

PHBG, SHA, SHB

SI, 5,2mm Ø diagonalsuspendededge length: 4mmtotal length: 18,6mm

SHA, SHB, suspensed

SI, 4,5mm Ø diagonalsuspensededge length: 3,6mmtotal length: 17,2mm

size 200 PHBH C/Z/E, PHBL

pump housing kit PHF, PHM

pump diaphragm PHF, PHM

single, plastic

single, metal

single, metal, 45°, PHM-S

double, metal

single, metal, SHA carburetor

plastic 45°, SHA carburetor

single, metal 25°, SHA carburetor

metal, SI 20, 24

metal, SHB

metal, SHA

6,5g, PHF, PHM

8,5g, PHF, PHM

3,7g SI

2,5 g SHA 10/12/13

3,5g SHA,SHB,SHBC

KIT 3.5 gr. PHBN, PHVA/B with needle valve and axlesContains:13679-22 Float axle13700-01 Float 3.5 gr15360-05 Float needle with small head

9,5g PHBH, PHBL

3,5g PHBN, PHVA

PHVA carburetor, Minarelli motor

PHVA carburetor, Morini motor

PHVA carburetor, Honda motor

PHVA carburetor, Peugeot motor

PHVA carbureto, Piaggio motor

KH-1377The set contains following articles:2 x float chamber gasket- Keyster = NTMOR-007G- OEM = 16010-MR5-5052 x float chamber valve set- Keyster = KHV-17020- OEM = 16011-MV1-7001 x main jet #118- Keyster = KHM-110118- OEM = 99101GHB11801 x main jet #122- Keyster = KHM-110122- OEM = 99101-GHB-12202 x throttle stop jet #42- Keyster = KHS-22B042- OEM = 99103-MV9-0420A2 x adjuter screw set- Keyster = KHSS-138- OEM = 16016-MV1-6302 x drain plug- Keyster = F-130- OEM = 16015-MV1-700before KH-1361

KK-0028The set contains following articles:float chamber gasket- Keyster = YFCG-1- OEM = F214106119- OEM = 16019-008top cover gasket- Keyster = M-15float chamber valve setadjuster screw setjet needle #Y41=5EJ15- Keyster = KYJ-0041main jet #98- Keyster = KYM-020098throttle stop jet #35- Keyster = KYS-00B035piston- Keyster = K-856PK

KK-0038The set contains following articles:float chamber gasket- Keyster = K-5float chamber valve setadjuster screw setjet needle #D46=013001-3main jet #105- Keyster = KHM-110105throttle stop jet #38- Keyster = KHS-05C038sealing surfacediv. O-rings (see ill.)

KK-0043The set contains following article:float chamber gasket- Keyster = YFCG-16C- OEM = 16019-029float chamber valve set- Keyster = KYV-20020jet needle #Y22=5DP2throttle stop jet #45- Keyster = KYS-020045adjuster screw setair idle jet- Keyster = MABM2125

KK-0046The set contains following articles:float chamber gasketfloat chamber valve setadjuster screw setjet needle #Y51=4EJ3main jet #85- Keyster = KYM-020085throttle stop jet #30- Keyster = KYS-00B030top cover gasket

KK-0049The set contains following articles:float chamber gasketfloat chamber gasketfloat chamber valve- Keyster = KYV-21016jet needle #Y77=4D93main jet #92- Keyster = KYM-01B092throttle stop jet #32div. O-rings (see ill.)

KK-0058NFThe set contains following articles:float chamber gasket- Keyster = K-10Ffloat chamber valve- Keyster = KVN-16R30- OEM = 16030-1007- OEM = 16030-028jet needle D108 = 272011needle jetmain jet #140- Keyster = KHM-110140throttle stop jet #38adjuster screw setcover gasketdiv. O-rings (see ill.)

KK-0069FThe set contains following articles:float chamber gasket- Keyster = K-35- OEM = 92055-1222float chamber valve- Keyster = KVN-16R30- OEM = 16030-1007- OEM = 16030-028adjuster screw set- Keyster = KHSS-493- OEM = 16014-1054jet needle #D478=N27Bjet needlepilot jetmain jet #132- Keyster = KHM-110132throttle stop jet #35- Keyster = KHS-05C035- OEM = 92064-1035drain plug

KK-0079The set contains following articles:float chamber gasket- Keyster = YFCG-37Bfloat chamber valve setadjuster screw setjet needle Y-134main jet #135- Keyster = KYM-020135throttle stop jet #42,5- Keyster = KYS-020042,5

KK-0092The set contains following articles:float chamber gasket- Keyster = YFCG-18Cfloat chamber valve setadjuster screw setjet needle #Y171=4FL44main jet #102,5- Keyster = KYM-020102,5throttle stop jet #25- Keyster = KYS-00B025top cover gasket

K-1014KKMThe set contains of following articles:float chamber sealingfloat chamber valve set- Keyster = KYV-50015- OEM = 16030-1088adjuster screw setdiv. O-rings (see ill.)

K-1042SKMThe set contains following articles:float chamber gasket- Keyster = NTMOR-021MG- OEM = 13258-33E00float chamber valve set with filter- Keyster = KYV-50015- OEM = 13370-20F00

K-1044YKMThe set contains of following articles:float chamber sealing- Keyster = NTMOR-021MG- OEM = 4XV-14562-00-00float chamber valve set- Keyster = KYV-50015- OEM = 4KM-14107-15-00adjuster screw set- Keyster = KYSS-260

K-1045YKMThe set contains following articles:float chamber gasket- Keyster = NTMOR-021MG- OEM = 4XV-14562-00-00float chamber valve set with filter- Keyster = KYV-50015- OEM = 4KM-14107-15-00adjuster screw set

K-1053HKThe set contains following articles:float chamber gasket- Keyster = NTMOR-004G- OEM = 16010-MZ5-920float chamber valve- Keyster = KVN-19N00- OEM = 16155-MN9-004jet needle J3WA=#D571- Keyster = KHD-0571Z- OEM = 16012-MAY-620pilot jet- OEM = 16165-MN4-013adjuster screw set- Keyster = KHSS-484- OEM = 16016-MZ2-E00throttle stop jet #38- Keyster = KHS-22B038- OEM = 99103-MV9-0380main jet #135- Keyster = KHM-110135- OEM = 99101-KPE-1350choke pistons- OEM = 16046-MY5-850drain plug- Keyster = F-130- OEM = 16023-MV9-670div. O-rings (see ill.)

K-1066HKThe set contains following articles:float chamber gasket- Keyster = NTMOR-004G- OEM = 16163-MZ5-920float chamber valve set- Keyster = KVN-16N00- OEM = 16155-413-751adjuster screw set- Keyster = KHSS-484- OEM = 16016-MAS-670jet needle #D567 = J6CC- Keyster = KHD-0567Z- OEM = 16012-MAL-600needle jet - OEM = 16165-MAL-980main jet #135- Keyster = KHM-110135- OEM = 99101-KPE-1350main jet #138- Keyster = KHM-110138- OEM = 99101-KPE-1380main jet #140- Keyster = KHM-110140- OEM = 99101-KPE-1400throttle stop jet #40- Keyster = KHS-22B040- OEM = 99103-MT2-0400choke pistons- OEM = 16046-MAL-600drain plug- Keyster = F-130- OEM = 16015-MZ5-920 (set no.)div. O-rings (see ill.)

K-1084SKMThe set contains following articles:float chamber sealing- Keyster = K67- OEM = 13258-04F00float chamber valve set- Keyster = KYV-50023- OEM = 13370-07F00- OEM = 13370-19E00div. O-rings (see ill.)

K-1138KKFThe set contains following articles:float chamber gasket- Keyster = NTMOR-015Gfloat chamber gasket- Keyster = NTMOR-016Gfloat chamber valve- Keyster = KVN-19A30- OEM = 16030-1057jet needle #D635= N53A- OEM 16009-1327- Canada accordanceadjuster screw set- Keyster = KHSS-493- OEM = 16014-1054main jet #132- Keyster = KHM-110132- Canada accordancechoke pistonsthrottle stop jet #38

K-1138KKRThe set contains following articles:float chamber gasket- Keyster = NTMOR-015Gfloat chamber gasket- Keyster = NTMOR-016Gfloat chamber valve- Keyster = KVN-19A30- OEM = 16030-1057jet needle #D636= N53B- OEM = 16009-1328- Canada accordanceadjuster screw set- Keyster = KHSS-493- OEM = 16014-1054main jet #132- Keyster = KHM-110132- Canada accordancechoke pistonsthrottle stop jet #38

K-1147SKFTeh set contains following articles:float chamber gasket- Keyster = NTMOR-013G- OEM = 1351-38A00float chamber valve set- Keyster = KYV-33L15- OEM = 13370-38B00adjuster screw- Keyster = KYSS-264- OEM = 13683-38B01- OEM = 13279-47070jet needle 5C29- Keyster = Y433- OEM = OEM = 13383-38E00needle jet D-459- Keyster = P-4- OEM = 09494-00592main jet #100- Keyster = KMM-010100- OEM = 09491-20019throttle stop jet #40- Keyster = KYS-060040- OEM = 09492-40021air jet #65- Keyster = MABM2-65- OEM = 09492-65005div. O-rings (see ill.)
