BIKE LIFT lift "Absolute 756 Gate"
electrohydraulic
- Art.-Nr.: 05762471
- Org.-Nr.: 997563010200
750kg load capacity, max. lifting height: 130cm, min. lifting height: 19cm, working surface: 220 x 75cm, ramp: 82 x 51cm, 260kg, total dimensions: 230 x 99cm, cable length of handset 2 m
Suitable for motorcycles and scooters. With retractable gate for easy disassembly of the rear wheel. Delivery incl. safety bar, tool tray and ramp.
Shipping instruction:
Each lifting platform will be delivered to you in a stable transport packaging by a forwarder with a truck that has a tail lift. Delivery within Germany (islands not included) approx. 2-3 working days after placing the order. An additional net shipping fee of 109.00€ is due.
Información sobre el producto
- Altura de elevación máx.: 130.0 cm
- Altura de elevación mín.: 20.0 cm
- Anchura: 99.0 cm
- Artículo: Article
- Carga: 750.0 kg
- Categoría: motorcycle / quad
- Longitud: 230.0 cm
- Propulsión: electrohydraulic
- Tensión de propulsión: 230.0 V
- Versión: lift
- Número de artículo del proveedor:: 997563010200
- EAN: 8053288165963
- UVP: 4.242,05 €
- Marca/Proveedor Bike-Lift
- Unidad de medida: PIECE
| Artículo | Precio | |
|---|---|---|
 BIKE LIFT aggregate-carrier plate for all Bike Lift lifting platforms (besides FROG, DUO, WIDER)
| ||
 BIKE LIFT Magnetic Coil for Brevini lowering valve unit (Brevini unit)
| ||
 BIKE LIFT Hand Switch without cable
| ||
 BIKE LIFT Lowering Valve Brevini lowering valve: QM CRP18E5magnetic coil: M14000007
| ||
 BIKE LIFT Control Unit control board with housing
| ||
 BIKE LIFT Cover for Bike Lift lifting platforms Absolut 756, Master 504, Max 504, Max 504 Twin Arms, Max 516, Max 516 Twin Arms
| ||
 BIKE LIFT Bolt top, Absolute 756 bolt diameter: 25mm
| ||
 BIKE LIFT Lowering Valve for Brevini lowering valve unit (Brevini unit)
| ||
 BIKE LIFT Roller below, 79,8 x 20,3 x 49,8/39,7
| ||
 BIKE LIFT Ramp black, for MAX 516 and ABSOLUTE 756
| ||
BIKE LIFT hydraulic aggregate complete, Gazzera
| ||
 BIKE LIFT Ramp red, for MAX 516 and ABSOLUTE 756
| ||
 BIKE LIFT Relay for Brevini lowering valve unit (Brevini unit)
| ||
 BIKE LIFT Bolt below, Absolute 756 bolt diameter: 20mm
| ||
 BIKE LIFT Hydraulic Cylinder lifting height: 130cm, red cylinder diameter: 70mmcylinder length: 460mmcylinder length (incl. bracket): 550mmpiston rod diameter: 40mmbracket inner diameter: 20mmbracket width: 80mm
| ||
 BIKE LIFT hydraulic aggregate cpmplete, Brevini
| ||
 BIKE LIFT Protection Mat lined red, for ABSOLUTE lift
| ||
 BIKE LIFT Hand Switch with cable
|
| Artículo | Precio | |
|---|---|---|
 BIKE LIFT Checker Plate "PZA-60" black
| ||
 BIKE LIFT Side Extension "SW756" red
| ||
 BIKE LIFT Side Extension "SW-SPIDER" red
| ||
 BIKE LIFT Rubber Mat "RM" 150 x 450 x 10mm (LxWxH)
| ||
 BIKE LIFT Wheel Holder "W-36 S" for tire width: 70-205mm
| ||
 BIKE LIFT Rubber Insert dimensions (LxWxH): 120 x 140 x 40mm
| ||
 BIKE LIFT Rubber Insert dimensions (LxWxH): 120 x 140 x 20mm
| ||
 BIKE LIFT foot pedal operating unit without cable
| ||
BIKE LIFT Rail Set red, for lift Absolute 756
| ||
 BIKE LIFT Scissor Jack adapter set (adjustable)
| ||
 BIKE LIFT Rubber Insert dimensions (LxWxH): 120 x 160 x 60mm
| ||
 BIKE LIFT Scissor Jack 500kg load capacity
| ||
 BIKE LIFT Scissor Jack 500kg load capacity
| ||
 BIKE LIFT Rubber Mat "RM" 330 x 450 x 10mm (LxWxH)
| ||
BIKE LIFT Wheel Holder "W-34 N" for tire width: 70-215mm
| ||
 BIKE LIFT Wheel Holder "W-42" black, for wheel diameter 12-21"
| ||
 BIKE LIFT Wheel Holder "W-38 S" for tire width: 60-170mm
| ||
BIKE LIFT drive-up ramp "R-MP3" red, for MAX 504, MAX 516 and ABSOLUTE 756
| ||
 BIKE LIFT Checker Plate "PZA-60" red
| ||
 BIKE LIFT Wheel Holder "W-42" red, for wheel diameter 12-21"
|
