max. wheel Ø 46", working range bead breaker blade 17”, wheel clamping diameter: 10" - 24"
Fully automatic tire changer with pneumatic rear-tilting mounting column and self-centering, pre-adjustable 4-clamping jaw system, as well as two double-acting clamping cylinders.

Note: plus freight and discharge costs

max. tire Ø: 1000mm (39"), max. tire width: 340mm (13")
Automatic tire changer, suitable for car and motorcycle tires. With tiltable mounting column, 2 speeds, pneumatic mounting arm lock and pneumatic bead presser.

Note: plus freight and discharge costs

Technical data:
rotation speed: 7 - 14 rpm
max. torque: 1200 Nm
motor power: 0,8 - 1,1 Kw
internal tension: 13" - 23" (adjustable from 12" - 22" or 14" - 24")
external tension: 11" - 21" (adjustable from 10" - 20" or 12" - 22")
working pressure: 10 bar (140 psi)
force of the bead breaker cylinder at 10 bar: 3000 kg

for motorcycles, outer rim tension 6 - 24", tire width: 2 - 10", tire Ø max. 960mm
With laterally pivoting mounting arm, eccentric clamping of the mounting head, self-centering clamping plate and powerful bead breaker cylinder. Clamping claws made of special steel for stable clamping of the rim from the outside, mounting head with adapter for a replaceable plastic element to protect the rims.

Technical data:
outer rim tension: 6 - 24"
tire width: 2 - 10"
tire diameter max.: 960 mm
compressed air conection: 8 - 10 bar
motor power: 0,75 / 1,1 kW
power connection: 400 V / 3 Ph / 50 Hz
sound level: < 70 db
weight: 215kg

special designed for motorcycle tires, max. tire diameter: 990mm, max. rim width: 12"
Chucking table with fixed clamping claws guaratnees maximum rigidity during assembly. With self-centering locking, internal clamping 12 - 19,5" and external clamping 5 - 24".
Technical data: pressure force: 3000kg, max. locking device turning moment: 1200 Nm, locking device turning speed: 6,5 rpm, three-phase motor: 400V / 50Hz / 0,55KW, working pressure: 8 - 10 bar, colour: anthracite / RAL 7016

max. tire diameter: 1050mm (41"), max. rim width: 12", tiltable
with double-acting bead break pistons from light metal, assembly paste holder, FS unit, self-centering clamping device and pedal operating. Assembly head working area 8 - 24", bead break shovel flexible and shaped, assembly head with aluminium rim protection, control of assembly head with automatic removal of the rim, metal side cover
Technical data: external clamping: 10 - 20", internal clamping: 12 - 22,5", bead break strength: 3600kg, motor power: 0,75 kW, turning speed: 7,3 rpm, max. torque: 1200 Nm, electro connection: 230 - 400 V / 50 - 60 Hz, colour: anthracite / RAL 7016

Note: plus freight and discharge costs

max. tire diameter 1050mm (41"), max. rim width 381mm (15")
Chucking table in two position adjustable claws, adjustable opening of the bead breaker, double-acting aluminium cylinder and a wide and reinforced housing guarantees a high rigidity of the structure and stability of the chucking table
Technical data: self-centring lock - external: 10" - 24", self-centring lock - internal: 12" - 26,5", tool working span: 8" - 24", colour: anthracite / RAL 7016

Note: plus freight and discharge costs

automatic, without tire lever, with pneumatic bead retractor, for tires Ø from 10-30", max. tire width: 15"
The leverless tire changer is equipped with a patented tool that allows fast and effortless work, even with new types of tires (ultra-low profile / RUN-FLAT tires). The central fixture with swivel plate, which is also suitable for drop-center rims, has a self-locking mechanism that makes the operator's work easier. The rotation speed can be adjusted at any time (0-15 rpm) thanks to an inverter motor (1.5 kW) with a speed limiter to protect the tire from excessive forces, colour: anthracie / RAL 7016
Scope of delivery: tire changer, incl. quick-release nut, auxiliary mounting arm, wheel lift and WDK-KIT

rim Ø: 10" - 30", wheel width 15", total wheel Ø 47"
Leverless tire mounting technology for work even with difficult wheel-tire combinations. A stepless inverter motor enables dynamic screwing in. This gives the bead enough time to slide into the drop center and reduces stress at the traction point to a minimum. No cables, chains or Bowden cables are required to adjust the tool. Already included in the scope of delivery: pneumatic auxiliary arm, bead chain, pedal controlled tire inflator, protection for aluminum rims / reverse mounting, stepless inverter motor (0 - 18 rpm)

Technical data:
wheel clamping diameter: 10" - 30"
max. wheel diameter: 1200mm / 47"
max. wheel width: 380mm / 15"
motor power: 1,5 kW - inverter
max. torque: 1200 Nm
speed: 0 - 18 rpm
max. opening bead breaker: 35"
bead pressure force on blade (10 bar): 12000 N
working pressure (recom.): 8 - 10 bar

automatic, without assembly lever, with pneumatic bead lifter, for tire Ø from 10-30", max. wheel width 15"
The leverless tire changer is equipped with a patented tool that allows fast and effortless work, even with new types of tires (ultra-low profile / RUN-FLAT tires). The central fixture with swivel plate, which is also suitable for drop-center rims, has a self-locking mechanism that facilitates the operator's work. The rotation speed can be adjusted, thanks to an inverter motor (1.5 kW) with speed limiter to protect the tire in case of excessive forces (0-15 rpm), colour: anthracie / RAL 7016
Scope of delivery: tire changer, incl. quick-release nut, auxiliary mounting arm, wheel jack and WDK-KIT

automatic, without assembly lever, for tire Ø from 10 - 30", max. wheel width 15"
The leverless tire changer is equipped with a patented tool that allows fast and effortless work, even with new types of tires (ultra-low profile / RUN-FLAT tires). The central fixture with swivel plate, which is also suitable for drop-center rims, has a self-locking mechanism that makes the operator's work easier. The rotation speed can be adjusted, thanks to an inverter motor (1.5 kW) with speed limiter to protect the tire in case of excessive forces (0-15 rpm), colour: anthracie / RAL 7016
Scope of delivery: tire changer
