1/2", for torque wrench, suitable for: 5121-1 CT, 5122-1 CT, 5123-1 CT

1/2", 28 - 210Nm
With easy release (only clockwise), reversible ratchet head, 24 teeth, accuracy: ±  4%, length: 465mm

1/2", 40 - 200 Nm
Ratchet mechanism and reverse lever for clockwise and anticlockwise rotation, clearly audible and palpable click signal when selected torque is reached. High accuracy according to ISO 6789: +/- 3%

1/2", 40 - 200 Nm, reversible ratchet with rotary mechnism, right-/left-hand torque
Noticeable click signal when the selected torque is reached, acuraccy ±4%, with fine scale (1 - 9 Nm), direct numerical indication of the desired torque value scale in the window and lock the handle by pull/push button. Length: 490mm

plastic box total sie (LxWxH): 530 x 75 x 115mm

1/2", 40 - 200 Nm, reversible ratchet, right-hand torque
Noticeable click signal when the selected torque is reached, acuraccy ±4%, direct numerical indication of the desired torque value scale in the window and lock the handle by pull/push button. Length: 505mm

plastic box total size (LxWxH): 525 x 80 x 70mm

1/2", 40 - 200 Nm, reversible ratchet, in Hexa pack
Adjustment of the desired torque value by turning the handle. ± 3% release accuracy tolerance of scale value (in direction actuaction), palpable (close gap release), audible ("click" sound). With integrated reversing lever, exact and fine scale graduation, safety locking of the handle, serial number and certificate. Square according to DIN 3120, ISO 1174-1, DIN EN ISO 6789:2003 (D)

Attention: for this torque wrench available are repair kits!

1/2", 40-200 Nm, reversible ratchet, 45 teeth
With square drive. Easy setting and saving of the desired torque value with audible and tactile clicks when reaching the scale values. Audible and tactile release mechanism when the set torque value is reached. Measuring range: 40-200 Nm; precision +/- 3% complies DIN EN ISO 6789-1:2017-07. Ergonomic 2-component handle for right-hand use. Weight: 1457g

1/2", 40 - 200 Nm, forward and reverse, tolerance +/- 4%
Reversible ratchet with controlled clockwise tightening, classified in acc. with DIN EN ISO 6789-2:2017, for the wheel change on the car. Incl. 1/2" extension and impact socket with protective sleeve (SW 17,19, 21).

1/2", reversible ratchet head (48 teeth), tolerance: +/-4%
With single actuation (only right-turn), numerical display of torque value, with calibration certificate and serial number, extra fine scale and safety button prevents accidental movement of torque setting ring. Ergonomic handle for convenient operation.

1/2", 10 - 60 Nm, extra short design, particularly compact
Accuracy ± 3% of scale value (in direction of actuation), adjustment of the desired torque value by turning the handle. Palpable (close gap release), audible ("click" sound), safe locking of the setting values by latching function on the rotary assembly. With integrated shift lever, easy-to-read scale, high-contrast scale, permanent readability due to laser marking on the scale bush, Serial number and certificate. Square acc. to DIN 3120, ISO 1174-1, DIN EN ISO 6789-2:2017. Total length: 320mm, net weight: 594g
Note: Also suitable for commercial vehicles.

Technical data:
number of teeth: 30 teeth
actuating force min.-max.: 3,9-25 kg
opening angle: 12°
head width: 32mm
head thickness: 14,5mm
scale graduation: 0.5 Nm
effective torque wrench length max. l1 mm : 244,2mm
effective torque wrench length min. l1 mm : 258,3mm
