chike Electric cargo bike "e-Cargo" (#1)
unisex, 16 / 20", melonengelb / grau, 5-speed SHIMANO "Nexus Di2" idle gear, 50 cm
Read more Read less - Article number: 02301012
- Original number: 4251971164895
Delivery only by forwarding agent. There are additional transportation costs of € 150.00.
Please note : Under the following link you will find step-by-step assembly/video instructions for the respective assembly.
https://chike.de/service/#Downloads
PU 1
Product information
- Battery capacity 630.0 Wh
- Bosch Smart System no
- Brake system hydraulic disc brake
- Colour designation melonengelb / grau
- Drive belt
- Drive system SHIMANO STEPS EP6
- Drive version middle motor
- E-bike yes
- Engine power 250 W
- Features electronic sliding aid , fender , system carrier
- Frame height 50 cm
- Frame shape unisex
- Gears 5-speed
- Gender unisex
- Main colour yellow
- Material 1 aluminium
- Maximum payload platform/box 80 kg
- Model series e-Cargo
- Permissible system weight 200 kg
- Secondary colour grey
- Shifting name 5-Gang SHIMANO "Nexus Di2" Leerlauf
- Shifting type internal gear shifting
- Support up to 25km/h
- Type transport bike
- Wheel size 16 / 20 "
- maximum load capacity Euroboxes 2_x_12 kg
- maximum load capacity of luggage rack 25 kg
- Battery SHIMANO "BT-EN606", 630 Wh
- Battery Lock AXA "Block XXL"
- Bottom bracket SHIMANO
- Brake TEKTRO Scheibenbremse Auriga Twin / Tetro Scheibenbremse T285
- Brake lever TEKTRO "HD-T525" / TEKTRO "HD-T285"
- Chain ring / pulley Gates "CDX", 55 teeth, belt line 45.5 mm
- Charger SHIMANO, 4 A
- Crank SHIMANO "FC-EM600", 170 mm
- Derailleur hanger chike Slider, from mod. 2021
- Display SHIMANO "SC-EN610", 4-levels, bluetooth, LCD color display, 31,8mm handlebar clamp
- Engine SHIMANO "DU-EP600-CRG"
- Fender Plastic, Set
- Fork Chike Neigetechnik
- Frame Aluminum, cargo frame, 50 cm
- Frame Lock AXA "Block XXL"
- Front hub BITEX "DH12N", 6-hole, 12 mm Thru Axle
- Front light Busch + Müller "IQ-XS E", 70 lux
- Front rotor TRP "TR-29", Ø 140 mm, 6-hole
- Front tire SCHWALBE "Big Apple", 50-305, Reflex
- Grips CONTEC "Ergo +", 133 mm, handlebar clamps, D3, black / gray
- Handlebar SATORI "Noirette", 630 mm, Ø 31.8 mm, 15° backsweep, 17 mm height
- Headset NECO, ZS44/28.6 / ZS44/30.0
- Other CHIKE "e-Cargo Transportplattform"
- Pedals CONTEC "Quick +"
- Rear carrier atranvelo "Tour 365"
- Rear hub SHIMANO "Nexus Di2 SG-C7050-5D", 5-speed, Center Lock
- Rear light SPANNINGA "Pimento XE"
- Rear rotor TRP "TRP-33", Ø 160 mm, 6-hole
- Rear tire SCHWALBE "Big Ben", 55-406, Reflex
- Rear wheel brake TEKTRO Disc Brakes "HD-T285", hydraulic, 2 pistons, 3 finger lever, for 1.8 mm brake rotors
- Remote SHIMANO "SW-EN600-R", right mountable, black
- Rims SCHUERMANN " Yak Disc" 25-305 24L SW / 25-406 36L SW
- Saddle CONTEC "Volare City EL"
- Seatpost satori "Astro", Ø 31.6 mm, 350 mm long, 20 mm offset
- Sensor SHIMANO Speedsensor 760mm
- Shifting lever SHIMANO "SW-EN600-L", left mountable, black
- Spokes 2,0 mm, Niro
- Sprocket / pulley Gates "CDX", 34 teeth
- Stem satori "UP2", aluminum, Ahead 1 1/8", 31.8 mm, handlebar clamps 110 mm, adjustable, black
- Supplier Article Number: 4251971164895
- EAN 4251971164895
- MSRP: €7,199.00
- Bidex-Code 129030
- DST-Code 1I01
- WEEE registration number DE92509320
- SB-Article No
- Fedas-Code 159023
- Brand/Supplier chike
- Unit of measure: PIECE
- Weight 39.5 kg
Product variants
Using the search field, you can refine the selection of product variants.
| Article | Price | |
|---|---|---|
 unisex, 16 / 20", melonengelb / grau, 5-speed SHIMANO "Nexus Di2" idle gear, 50 cm Read more Read less
| PU 1 | |
 unisex, 16 / 20", salbei / grün matt, 5-speed SHIMANO "Nexus Di2" idle gear, 50 cm Read more Read less
| PU 1 | |
 unisex, 16 / 20", schwarz / sand matt, 5-speed SHIMANO "Nexus Di2" idle gear, 50 cm Read more Read less
| PU 1 |
