CONTEC Rear Hub "Core CL"
12-speed Shimano Micro Spline, installation width 142 mm, approx. 397 g
- Article number: 07476220
- Original number: CL-RTP MICROSPLINE
32 hole, Center Lock disc brake mount, for 12 mm Thru Axle, suitable for E-bikes, black
Aluminum hub body, ball bearings, robust steel Freewheel Body, 27-tooth ratchet freehub system, 3 pawl arrangement
Product information
- Axle 12mm full-floating axle
- Axle diameter 12.0 mm
- Brake mounting disc - Center Lock
- For wheel standard
- Freewheel body Micro Spline
- Freewheel body material aluminium
- Hole 32 holes
- Installation width 142,0 mm
- Main colour black
- Mounting rear wheel
- Range of application MTB
- System compatibility 12-speed
- Text wheel configurator suitable for E-bike
- Type cassette
- Variant Article
- Supplier Article Number: CL-RTP MICROSPLINE
- EAN: 4251971137950
- MSRP: €79.95
- Fedas-Code: 160452
- SB-Article: No
- Bidex-Code: 204030
- DST-Code: 2P04
- Brand/Supplier CONTEC
- Unit of measure: PIECE
- Weight: 0.397 kg
| Article | Price | |
|---|---|---|
 12-speed Shimano Micro Spline, approx. 196g Read more Read less
| ||
 suitable for Core CL / M.Core CL rear hubs with Microspline Freewheel Body (0.747.622/0, 0.747.622/3, 0.747.620/0) Read more Read less
| ||
 suitable for "Core CL" rear hubs with Microspline freewheel, Set of 6 industrial bearings (2x 17 x 28 x 7, 4x 15 x 26 x 7L), for 0.747.622/0, 0.747.622/3 Read more Read less
|
With our Core hubs, you can build your wheels reliably and robustly for all the challenges of daily use. Their outstanding quality also makes them ideal for use on e-bikes. Made from aluminum, the Core rear hub offers 32 spoke holes, Center Lock brake disc mount, 12 mm Thru Axle and is designed for an installation width of 142 mm. The Microspline steel Freewheel Body is deliberately designed for robustness and durability, as is the use of high-quality ball bearings. The ratchets freehub system with 27 teeth and 3 Pawls offers fast interaction between the freehub and hub body, so that your pedal stroke is quickly converted into propulsion.
Product variants
Using the search field, you can refine the selection of product variants.
| Article | Price | |
|---|---|---|
 11-/12-speed SRAM XD, installation width 142 mm, approx. 357 g Read more Read less
| ||
 11-/12-speed SRAM XD, mounting width 148 mm (booster), approx. 366 g Read more Read less
| ||
 12-speed Shimano Micro Spline, installation width 142 mm, approx. 397 g Read more Read less
| ||
12-speed Shimano Micro Spline, mounting width 148 mm (booster), approx. 405 g Read more Read less
| ||
8-/9-/10-/11-speed Shimano HG-M, MTB freewheel body (34.9 mm), mounting width 142 mm, approx. 373 g Read more Read less
| ||
 8-/9-/10-/11-speed Shimano HG-M, MTB Freewheel Body (34.9 mm), mounting width 148 mm (Boost), approx. 381 g Read more Read less
|
