application: cross country, specially designed for smaller and lighter riders
spring: Solo Air
adjustment: air pressure via Schrader valve
damping: rebound
adjustment: external rebound
steering tube: aluminium, approx. 265mm, tapered 1,5" to 1 1/8" ahead
crown: hollow forged aluminium
stanchion: aluminium, 32mm Ø
sliders: magnesium, for PM disc brake 160 up to 220mm Ø, 40mm offset, max. tire width 63mm
accessories: 15 x 100mm Maxle Stealth axle, ahead clamp
weight: 1585g

application: dirt jump
spring: Solo Air
adjustment: air pressure via Schrader valve
damping: Charger
adjustment: external rebound, low speed compression
steering tube: aluminium, approx. 265mm, tapered 1,5" to 1 1/8" ahead
crown: hollow forged aluminium 7050
stanchion: aluminium, low friction anodized, 35mm Ø
sliders: magnesium, for PM disc brake 160 up to 220mm Ø, 40mm offset, max. tire width 66mm
accessories: 15 x 100mm Maxle Stealth axle, ahead clamp

26", 80mm travel, steel spring, without steering tube
Preload adjuster, aluminium black satined fork brace, CroMo black stanchion 30mm, magnesium sliders, for rim and disc brake rotor (Post Mount), approx. 2,21kg

100mm travel, suspension oil right/steel spring left, without steering tube, for 1" or 1 1/8" steering tubes
Preload adjuster, hydraulic pressure range, aluminium black satined fork brace, CroMo chrome coated polished stanchion 30mm, aluminium sliders, for rim and disc brake mount (Post Mount), approx. 2,44kg

travel 80/100/120mm, steel spring / elastomer, incl. ahead steering tube 28,6 x 255mm 1 1/8"
9mm quick-release dropouts, for rim and disc brake (post mount) alloy downtube assortment, steel steering tube, stanchion Ø 30mm (XCM30), black

travel 50mm, steel spring / elastomer, incl. ahead steering tube 28,6 x 255mm, 1 1/8"
city bike suspension fork with 9mm QR dropouts, for rim brake, one part bridge from aluminium, integrated holder for Suntour light, with hole for light bracket, suitable for E-bikes and Pedelecs

travel 50mm, steel spring / elastomer, incl. steering tube 28,6 x 190mm, 1 1/8" / 40mm thread
city bike suspension fork with 9mm QR dropouts, for rim brake, one part bridge from aluminium, integrated holder for SR Suntour light, with hole for light bracket, suitable for E-bikes and Pedelecs

travel 50mm, steel spring / elastomer, incl. ahead steering tube 28,6 x 255mm, 1 1/8"
trekking bike suspension fork with 9mm QR dropouts, for PM disc brake (160mm), one part bridge from aluminium, integrated holder for Suntour light, with hole for light bracket
