aplication: gravel
spring: Solo Air
adjustment: air pressure via Schrader valve
damping: Charger Race Day 2
adjustment: external rebound, external compression 2-stage: open/lockout
steering tube: aluminium, approx. 265mm, tapered 1,5" to 1 1/8" ahead
crown: hollow forged aluminium
stanchion: aluminium, 30mm Ø
sliders: magnesium, for FM disc brake 160 up to 180mm Ø, max. tire width: 50mm (700C)
accessories: Maxle Stealth thru axle 12 x 100mm, plug-in fender, ahead clamp

spring: Solo Air
adjustment: air pressure via Schrader valve
damping: Motion Control
adjustment: compression up to lockout
steering tube: aluminium, approx. 265mm, 1 1/8" ahead
crown: aluminium, forged, black
stanchion: aluminium, 30mm Ø
sliders: magnesium
weight: approx. 1827g

60mm travel, oil right / steel spring left lockable, without steering tube for 1" and 11/8"
Preload adjuster, fork brace from aluminium black, light bracket retrofitted, aluminium sliders with mounted cable guide for light cable, CroMo stanchion 28,6mm, rebound hydraulic adjustment, for rim brake, suitable for E-Bikes and Pedelecs, approx. 2,31kg

travel 50mm, steel spring / elastomer, incl. ahead steering tube 28,6 x 255mm, 1 1/8"
city bike suspension fork with 9mm QR dropouts, for rim brake, one part bridge from aluminium, integrated holder for Suntour light, with hole for light bracket, suitable for E-bikes and Pedelecs

travel 50mm, steel spring / elastomer, incl. steering tube 28,6 x 210mm, 1 1/8" / 55mm thread
city bike suspension fork with 9mm QR dropouts, for rim brake, one part bridge from aluminium, integrated holder for SR Suntour light, with hole for light bracket, suitable for E-bikes and Pedelecs

travel 50mm, steel spring / elastomer, incl. ahead steering tube 28,6 x 255mm, 1 1/8"
city bike suspension fork with 9mm QR dropouts, for Post Mount disc brake (160mm), one part bridge from aluminium, integrated holder for Suntour light, with hole for light bracket, suitable for E-bikes and Pedelecs

50mm travel, steel spring / elastomer, incl. steering tube 28,6 x 255mm 1 1/8" / 40mm thread
9mm QR dropouts, for rim brake, with hole for light bracket

travel 50mm, steel spring / elastomer, incl. steering tube 28,6 x 255mm, 1 1/8" / 55mm thread, with lockout function
city bike suspension fork with 9mm quick release dropouts, for tires up to 48mm, for rim brake / V-brake, one-piece bridge made of aluminium, integrated mount for Suntour light, with hole for light bracket, with long fender mount, 2700g, suitable for e-bikes and Pedelecs

travel 50mm, steel spring / elastomer, incl. steering tube 28,6 x 255mm, 1 1/8" / 55mm thread
city bike suspension fork with 9mm quick release dropouts, for tires up to 48mm, for rim brake / V-brake, one-piece bridge made of aluminium, integrated mount for Suntour light, with hole for light bracket, with long fender mount, 2485g, suitable for e-bikes and Pedelecs

60mm travel, oil right / steel spring left lockable, without steering tube for 1" and 11/8"
Preload adjuster, aluminium black fork brace, light bracket retrofitted, aluminium slidres with mounted cable guide for light cable, CroMo stanchion 28,6mm, rebound hydraulic adjustment, for rim and disc brake (IS adapter), max. disc brake diameter 180mm, suitable for E-Bikes and Pedelecs, approx. 2,3kg
