travel approx. 30mm, spring rate: 150kg, e-bike ready, black anodized, ST = short travel
self-service package, 3D forged aluminium, stack height approx. 99mm, fine response characteristic, high ride comfort, Igus polymer high performance plain bearings, easy spring and saddle exchange, saddle clamp with fine adjusting and robust grating, defined adjustment range with stop, shaft can be shortened (outer Ø 34,9mm), incl. mud cover

travel approx. 50mm, spring rate: 150kg, e-bike ready, black anodized, LT = long travel
self-service package, 3D forged aluminium, installation height approx. 130mm, fine response characteristic, high ride comfort, Igus polymer high performance plain bearings, easy spring and saddle exchange, saddle clamp with fine adjusting and robust grating, defined adjustment range with stop, shaft can be shortened (outer Ø 34,9mm), incl. mud cover, from 810g

50mm travel, spring rate up to 120kg, 350mm long, anodized black
self-service package, aluminium 6061, 2-bolt clamp mechanism, high comfort and flexibility

40mm travel,spring rate up to 120kg, 350mm long, matt black
self-service package, aluminium 6061, 2-bolt clamp mechanism

58mm travel (36,5mm horizontal / 58mm vertical), air and steel suspension, spring rate from 40-120kg individually adjustable due to adjustable PSI air suspension, 25mm offset, matt black sandblasted
self-service package, aluminium 6061, installation height 110mm, high ride comfort due to double suspension, adjustable with suitable damper pump (e.g. 0.331.916/7 or 0.331.734/4)

50mm travel, air suspension, 350mm long, black / taupe anodized
self-service package, aluminium 6061, 2-bolt clamp mechanism, higher protection against paint damage and smoother height adjustment due to extra PTFE coating, adjustable without putting down the saddle, suspension response can be varied by preload adjustment

50mm travel, air suspension, 350mm long, sandblasted black
self-service package, aluminium 6061, 2-bolt clamp mechanism, adjustable without taking off the saddle, suspension response can be varied by preload setting

27mm travel (15mm horizontal / 23mm vertical), spring rate: 70 - 90kg, black
Level 5, e-Bike ready according to ergotec Safety Level Table, self-service package, aluminium, 7mm rail, 2 screws clamp, 30-60mm offset, installation height: 111mm, interchangeable springs, approx. 612g

45mm travel, MCU and springs, spring rate: 60-80kg, 350mm long
level 4, e-Bike ready according to ergotec Safety Level Table, self-service package, aluminium 6061 T6, E-bike compatible, approx. 550g

45mm travel, steel springs, spring rate: 70-120kg, 350mm long, offest: 15mm, sandblasted black
Level 5, e-bike ready according to ergotec Safety Level Table, self-service package, aluminium 6061 T6, stack height: 100mm, e-bike compatible, approx. 535-610g
