1/4", 5 - 25 Nm, reversible ratchet with rotary mechnism, right-/left-hand torque
Noticeable click signal when the selected torque is reached, acuraccy ±4%, with fine scale (0,2 - 1,8 Nm), direct numerical indication of the desired torque value scale in the window and lock the handle by pull/push button. Length: 300mm

plastic box total size (LxWxH): 430 x 75 x 55mm

3/8", 20 - 100 Nm, reversible ratchet with rotary mechnism, right-/left-hand torque
Noticeable click signal when the selected torque is reached, acuraccy ±4%, with fine scale (0,5 - 4,5 Nm), direct numerical indication of the desired torque value scale in the window and lock the handle by pull/push button. Length: 385mm

plastic box total size (LxWxH): 430 x 75 x 55mm

1/2", 40 - 200 Nm, reversible ratchet with rotary mechnism, right-/left-hand torque
Noticeable click signal when the selected torque is reached, acuraccy ±4%, with fine scale (1 - 9 Nm), direct numerical indication of the desired torque value scale in the window and lock the handle by pull/push button. Length: 490mm

plastic box total sie (LxWxH): 530 x 75 x 115mm

1/4", 5 - 25 Nm, reversible ratchet, right-hand torque
Noticeable click signal when the selected torque is reached, acuraccy ±4%, with fine scale (0,1 Nm), direct numerical indication of the desired torque value scale in the window and lock the handle by pull/push button. Length: 255mm

plastic box total size (LxWxH): 310 x 75 x 60mm

3/8", 20 - 100 Nm, reversible ratchet, right-hand torque
Noticeable click signal when the selected torque is reached, acuraccy ±4%, with fine scale (0,5 Nm), direct numerical indication of the desired torque value scale in the window and lock the handle by pull/push button. Length: 415mm

plastic box total size (LxWxH): 495 x 80 x 65mm

1/2", 40 - 200 Nm, reversible ratchet, right-hand torque
Noticeable click signal when the selected torque is reached, acuraccy ±4%, direct numerical indication of the desired torque value scale in the window and lock the handle by pull/push button. Length: 505mm

plastic box total size (LxWxH): 525 x 80 x 70mm

1/4", 2,5 - 25 Nm, reversible ratchet, 20 teeth
For controlled screw tightening in tyre service, bicycle, passenger car and commercial vehicle applications as well as various applications in trade and industry. Tolerance: ± 3%. Tightening with set torque is possible both to the right and to the left. Fast adjustment of the desired torque value by turning the handle, safe locking of the setting values by latching function on the rotary assembly, rotary assembly in triangular form prevents uncontrolled rolling. Laser marking on the scale bush, tested after DIN EN ISO 6789-2:2017, with calibration certificate and serial number.

3/8", 10 - 60 Nm, reversible ratchet with integrated switch lever
Accuracy ± 3% of scale value (in direction of actuation), setting the desired torque value by turning the handle. Palpable (close gap release), audible ("click" sound). Adjustment aid with detent points, rotary assembly in triangular form prevents uncontrolled rolling, easy-to-read, high-contrast scale. Tested in acc. with DIN EN ISO 6789-2:2017, square after DIN 3120, ISO 1174-1, DIN EN ISO 6789-2:2017, with calibration certificate and serial number, total length: 320mm.

1/2", 10 - 60 Nm, extra short design, particularly compact
Accuracy ± 3% of scale value (in direction of actuation), adjustment of the desired torque value by turning the handle. Palpable (close gap release), audible ("click" sound), safe locking of the setting values by latching function on the rotary assembly. With integrated shift lever, easy-to-read scale, high-contrast scale, permanent readability due to laser marking on the scale bush, Serial number and certificate. Square acc. to DIN 3120, ISO 1174-1, DIN EN ISO 6789-2:2017. Total length: 320mm, net weight: 594g
Note: Also suitable for commercial vehicles.

Technical data:
number of teeth: 30 teeth
actuating force min.-max.: 3,9-25 kg
opening angle: 12°
head width: 32mm
head thickness: 14,5mm
scale graduation: 0.5 Nm
effective torque wrench length max. l1 mm : 244,2mm
effective torque wrench length min. l1 mm : 258,3mm

1/2", 20 - 120 Nm, integrated shift lever with free-running function
Accuracy ± 3% of scale value (in direction of actuation). Wide range of applications for controlled screw tightening in tyre service, bicycle, passenger car and commercial vehicle applications as well as various applications in trade and industry. Optimised sealing ring to protect against debris, adjustment aid with detent points for optimised operator guidance, safe locking of the setting values by latching function on the rotary assembly, can be attached to the cable loop, easy-to-read, permanent readability due to laser marking on the scale bush. Tested after DIN EN ISO 6789-2:2017, incl. calibration certificate and serial number. Delivery in stable Hexa plastic pack.
