CONWAY Electric allroad "Nyvon 9.0" Mod. 24
diamond, 28", graphitegrey matt / silver matt, 12-speed SRAM "Apex", 54 cm / XL
Read more Read less - Article number: 02830118
- Original number: 01025584
The electric all-road bike consists of a carbon frame and is equipped with a BOSCH Performance Line SX mid-motor, which offers 250 W of power. The battery capacity is 400.0 Wh. Drives are provided by a chain drive. A 12-speed SRAM "Apex" derailleur is installed for gear selection. The braking system includes hydraulic disc brakes. The wheel size is 28". The permissible system weight is 130 kg.
Product information
- Battery capacity 400.0 Wh
- Bosch Smart System yes
- Brake system hydraulic disc brake
- Chainstay 440 mm
- Colour designation graphitegrey matt / silver matt
- Drive chain drive
- Drive system BOSCH Performance Line SX
- Drive version middle motor
- E-bike yes
- Engine power 250 W
- Frame height 54 cm
- Frame shape diamond
- Frame size XL
- Gears 12-speed
- Gender gents
- Main colour grey
- Material 1 carbon
- Permissible system weight 130 kg
- Reach 412 mm
- Seat angle 74.0 °
- Seat tube 540 mm
- Secondary colour silver
- Shifting name 12-Gang SRAM "Apex"
- Shifting type derailleur shifting
- Stack 622 mm
- Standover height 848 mm
- Steering tube 175 mm
- Steering tube angle 71.5 °
- Stem length 110.0 mm
- Support up to 25km/h
- Toptube 590 mm
- Transmission 1x 12-speed
- Type allroad
- Wheel distance 1081 mm
- Wheel size 28 "
- Battery: BOSCH "CompactTube 400", 400 Wh
- Battery Lock: ABUS "XPlus"
- Bottom bracket: BOSCH
- Brake: SRAM "Apex"
- Brake lever: SRAM "Apex"
- Chain ring / pulley: MIRANDA, 42 teeth
- Charger: BOSCH 2 A
- Crank: MIRANDA "Omega", 170 mm, for Bosch Gen. 4, ISIS, Q: 8, black
- Derailleur hanger: SRAM "UDH", for Thru Axle, 1 mm thread pitch
- Engine: BOSCH "Performance Line SX", max. 60 Nm
- Fork: Carbon, tapered 1 1/8" - 1.5", flat mount
- Frame: Intube Bosch, Gen. 4, BES3, Carbon, Diamant, 54 cm
- Front hub: MAVIC "Allroad 1 CL", 12 x 100 mm
- Front light: SUPERNOVA "Mini 2", 100 Lux, 235 Lumen, Handlebar Bracket 31.8 mm
- Front rotor: SRAM "Centerline", Ø 160 mm, Centerlock
- Front tire: SCHWALBE "G-One Allround", 45-622
- Grips: FIZIK "Tempo Microtex Bondcush Soft", black
- Handlebar: SATORI "X-Race Aero", 440 mm, Ø 31.8 mm, Reach 70 mm, Drop 122 mm, Flare 16°
- Headset: ACROS IS52/28.6 / IS52/39.8, ICR
- Laufrad H.R.: MAVIC "Allroad 1", 12 x 142 mm, Thru Axle, Center Lock
- Rear derailleur: SRAM "Apex XPLR"
- Rear hub: MAVIC "Allroad 1 CL", 12 x 142 mm
- Rear rotor: SRAM "Centerline", Ø 160 mm, Centerlock
- Rear tire: SCHWALBE "G-One Allround", 45-622
- Remote: BOSCH "Mini Remote"
- Rims: MAVIC
- Saddle: Selle Royal "SRX", Athletic
- Seatpost: satori "Trident OF", Ø 27.2 mm, 350 mm long
- Sensor: Pedal pressure measuring im Motor + speed sensor
- Spokes: MAVIC
- Stem: satori "New Viper",1 1/8", 31,8 mm Lenkerklemmung, 110 mm lang, Winkel -7°, ICR, schwarz
- System Interface: BOSCH "BRC3100"
- Supplier Article Number: 01025584
- EAN: 4251971149793
- MSRP: €4,399.95
- WEEE registration number: DE92509320
- Fedas-Code: 154020
- Bidex-Code: 121010
- DST-Code: 1E01
- SB-Article: No
- Brand/Supplier CONWAY
- Unit of measure: PIECE
- Weight: 15.2 kg
| Article | Price | |
|---|---|---|
 left, without shift lever, front brake with 1300mm line Read more Read less
| ||
 for Cairon BES3 (Z11 / Z12), Xyron BES3 aluminium and carbon (Z11), Cairon SUV FS BES3 (Z14) and Nyvon (Z17) Read more Read less
| ||
 | ||
 right, with shift lever 12-speed, rear brake with 2000mm line Read more Read less
| ||
 non plug sideNote: mount. screws (0.230.350/1) are not incl.! Read more Read less
| ||
 suitable for New Viper stem, e.g. suitable for Conway Nyvon (Z17) Read more Read less
| ||
 Plastic, suitable for Nyvon (Z17) Read more Read less
| ||
 plug sideNote: mounting screws (0.230.350/1) are not incl.! Read more Read less
| ||
 | ||
 | ||
 industrial bearings, IS52/IS52, ICR, suitable for Nyvon (Z17) Read more Read less
| ||
 UDH, suitable for eWME (Z10), Nyvon (Z17), Ryvon (Z18) and Xyron ST / LT (Z20)(equivalent substitute: 0.347.028/3) Read more Read less
| ||
 | ||
 | ||
 Suitable for the smart system (BES3)Note: only for battery sizes CPT400 , PT500, PT625, PT750 Read more Read less
| ||
 Ø 160mm, without lockring Read more Read less
| ||
 suitable for Nyvon Z17, hub standard 12 x 100 mm, total length 119 mm, thread pitch M12 x 1.0, thread length 15 mmNote: matching Locking Lever 0.281.503/3 Read more Read less
| ||
 suitable for eWME (Z10), Ryvon (Z18), matching thru axle 0.281.502/5 and Nyvon (Z17), matching thru axle 0.747.383/0 Read more Read less
| ||
 graphite gray matt (YS 9309-1 matt) Read more Read less
| ||
 suitable for Nyvon (Z17), hub standard 12 x 142 mm, total length 172 mm, thread pitch M12 x 1.0, thread length 14.5 mm, for UDHNote: matching Locking Lever 0.281.503/3 Read more Read less
| ||
 suitable for all Bosch chargers Read more Read less
| ||
 | ||
 without pin release, horizontal Read more Read less
| ||
 for cassettes 10/11 - 44 teeth Read more Read less
| ||
 | ||
 for VR, incl. screw, suitable for Nyvon (Z17) Read more Read less
| ||
 | ||
 | ||
 11-12-13-15-17-19-21-24-28-32-38-44 teeth Read more Read less
| ||
 black, fits Conway eWME from 2021 and Victoria eParcour, among others Read more Read less
| ||
 | ||
 | ||
 Chainring Spiderless Read more Read less
| ||
 integrated, suitable for GRV Carbon (from 2022) and Nyvon (Z17) Read more Read less
| ||
 | ||
 Complete, suitable for Nyvon (Z17) Read more Read less
| ||
 for down tube inner side, suitable for Nyvon (Z17), Ryvon (Z18) and Xyron LT / ST (Z20)(Only two brackets are required for Nyvon models) Read more Read less
| ||
 | ||
 |
Arrive instead of giving up! Thanks to the Bosch SX engine, you get tailwind where you need it - and take the fear out of long distances or steep sections. Our "NYVON" offers the perfect synthesis of e-bike and purist gravel bike, a fast carbon chassis with just the right amount of power you need.Precise, accurate handling, a comfortable, sporty riding position and directional stability ensure a well-rounded riding experience on gravel, road and all routes beyond. If your tour takes you from dawn to dusk, you have a powerful front light on board from the factory to illuminate your path properly.The "NYVON" also offers 5 mounting points for luggage and a kickstand mount for direct attachment to the rear triangle. The Bosch Control Unit is positioned centrally on the top tube, which you can also operate from the Handlebar using the mini-remote without having to reach around.
Product variants
Using the search field, you can refine the selection of product variants.
| Article | Price | |
|---|---|---|
 diamond, 28", graphitegrey matt / silver matt, 12-speed SRAM "Apex", 45 cm / S Read more Read less
| ||
diamond, 28", graphitegrey matt / silver matt, 12-speed SRAM "Apex", 48 cm / M Read more Read less
| ||
diamond, 28", graphitegrey matt / silver matt, 12-speed SRAM "Apex", 51 cm / L Read more Read less
| ||
diamond, 28", graphitegrey matt / silver matt, 12-speed SRAM "Apex", 54 cm / XL Read more Read less
|
