CONWAY Electric MTB full suspension "Xyron S 5.0 Carbon" (#1)
full suspension, 29 / 27,5", desert matt / plum matt, 12-speed SRAM "SX NX GX Eagle", 46 cm / L
Read more Read less - Article number: 02810153
- Original number: KCW25XY1032
The bike has a carbon frame. It comes with a Suspension Fork that has a fork travel of 150 mm. The frame suspension travel is 160 mm. The permissible total weight is 130 kg. The drives are powered by a chain. The drive system is based on a BOSCH mid-motor with a motor output of 250 W. The gears are a 12-speed SRAM "SX NX GX Eagle". The wheel size is 29" / 27". The brake system consists of a hydraulic disc brakes. The battery capacity is 750.0 Wh.
Product information
- Battery capacity 750.0 Wh
- Brake system hydraulic disc brake
- Category full suspension
- Category E-bike 3
- Colour designation desert matt / plum matt
- Drive chain drive
- Drive system BOSCH Performance Line CX
- Drive version middle motor
- E-bike yes
- Engine power 250 W
- Features electronic sliding aid
- Frame height 46 cm
- Frame shape full suspension
- Frame size L
- Frame travel 160 mm
- Gears 12-speed
- Gender gents
- Main colour beige
- Material 1 carbon
- Seat angle 74.5 °
- Secondary colour purple
- Shifting name 12-Gang SRAM "SX NX GX Eagle"
- Shifting type derailleur shifting
- Steering tube angle 64.5 °
- Support up to 25km/h
- Transmission 1x 12-speed
- Travel 150 mm
- Battery Lock: AXA "New Lock", for PowerTube, BES3
- Bottom bracket: BOSCH
- Brake: MAGURA "MT5 E-Stop", 4/4-Kolben
- Brake lever: MAGURA "MT5 E-Stop"
- Chain / belt: SRAM "SX Eagle"
- Derailleur hanger: CONWAY für WME carbon, Xyron, RLC FS, Cairon SUV FS, from mod.20
- Display: BOSCH "Kiox 300", 4-stages, remote control, push aid
- Frame: Intube Bosch, Gen. 4, BES3, Carbon, Fullsuspension, 46 cm
- Front hub: FORMULA "DC 711", 15 x 110mm, 6-hole, 32 holes, thru axle, black
- Front tire: SCHWALBE "Magic Mary", Evolution Line 62-622, Super Trail, Addix Soft, TLE, foldable, 67 TPI, E-50
- Grips: SQLAB "70X", size M, 135 mm, black
- Handlebar: LEVELNINE "Race Riser", 780mm, Ø 31,8mm, backsweep 9°, rise 15mm, black
- Rear derailleur: SRAM "GX Eagle"
- Rear hub: FORMULA "EHL-148S", 12 x 148mm, 6-hole, 11-speed HG, 32 holes, thru axle, black
- Remote: BOSCH "BRC3300", Mini Remote
- Rims: RODI "Ready 30"
- Saddle: FIZIK "Terra Aidon X5", unisex, type 2, regular, L 255 x W 145 mm black
- Seatpost: CONTEC adjustable seatpost "Drop-A-Gogo", Ø 31.6 mm, 440 mm long, 150 mm adjustment range, black
- Sensor: Pedal pressure measuring im Motor + speed sensor
- Spokes: MACH 1 "PRO"
- System Interface: BOSCH "BRC3100"
- Supplier Article Number: KCW25XY1032
- EAN: 4251971155183
- MSRP: €5,999.95
- DST-Code: 1E01
- Bidex-Code: 121020
- Brand/Supplier CONWAY
- Unit of measure: PIECE
- Weight: 25.4 kg
- Konformitätserklärung DE
- Konformitätserklärung ES
- Explosionszeichnung Grease
- Explosionszeichnung Torque
- Explosionszeichnung Metall
- Konformitätserklärung FR
- Konformitätserklärung DK
- Konformitätserklärung EN
- Bedienungsanleitung
- Explosionszeichnung Kunststoff & Gummi
- Konformitätserklärung IT
- Konformitätserklärung NL
| Article | Price | |
|---|---|---|
 suitable for Xyron Carbon, BES3 (Z11) Read more Read less
| ||
 suitable for Cairon / Xyron (Z11) Read more Read less
| ||
 | ||
 11-13-15-17-19-22-25-28-32-36-42-50 teeth Read more Read less
| ||
 suitable for eWME (Z10), Ryvon (Z18), matching thru axle 0.281.502/5 and Nyvon (Z17), matching thru axle 0.747.383/0 Read more Read less
| ||
 suitable for all Xyron Carbon, WME (Z7), Ryvon (Z18), M12x1.0, shaft length 30.5 mm Read more Read less
| ||
 suitable for Cairon trapeze and gents with thru axle and Xyron, Smart system, BES3 (Z11) Read more Read less
| ||
 | ||
 | ||
 12 x 148mm, 180mm long, 1,75mm thread pitch, Boost Read more Read less
| ||
 | ||
 for Cairon BES3 (Z11 / Z12), Xyron BES3 aluminium and carbon (Z11), Cairon SUV FS BES3 (Z14) and Nyvon (Z17) Read more Read less
| ||
 | ||
 | ||
 Suitable for the smart system (BES3)Note: only for battery sizes CPT400 , PT500, PT625, PT750 Read more Read less
| ||
 for Damper, suitable for eWME from 2021 (Z10), Xyron 27.5" (Z6) and Xyron 29" (Z11), for Xyron 29" SUV fits 0.281.780/7 (long version). Read more Read less
| ||
 | ||
 suitable for Cairon (Z11 and Z12), Cairon SUV FS (Z14) and Xyron (Z11), Gen.4 (Performance CX), smart system (BES3) Read more Read less
| ||
 | ||
 | ||
 WME Carbon / Xyron / RLC FS / Cairon SUV FS, Mod.20 Read more Read less
| ||
 suitable for Cairon trapeze and gents (Z11, Z12, Z14) and Xyron (Z11), Smart system, Gen.4 (Performance Line CX), BES3 Read more Read less
| ||
 | ||
 203 mm, old packaging Read more Read less
| ||
 | ||
 | ||
 | ||
 for damper, suitable for Xyron aluminium and carbon, BES3 with smart system (Z11) Read more Read less
| ||
 | ||
 32 holes, 110mm, 15mm thru axle Read more Read less
| ||
suitable for Xyron S 5.0 desert matt / plum matt, Mod. 2025 (Z11) Read more Read less
| ||
 Ø 31,6mm, 440mm long, 150mm adjustment range Read more Read less
| ||
 black, single click (shifts one gear per shifting operation), optimized for the E-bike use Read more Read less
| ||
 | ||
 suitable for WME (Z7), 180 mm / M12 x P1, 75 x 20 mm Read more Read less
| ||
 | ||
 suitable for WME Carbon (Z7) and Xyron Carbon BES2 and BES3 (Z6 / Z11), for Xyron Alu the spacer 0.281.070/0 is also required Read more Read less
| ||
suitable for Xyron Carbon S 5.0, desert matt / plum matt, Mod. 25 (Z11) Read more Read less
| ||
 | ||
 | ||
 suitable for all Bosch chargers Read more Read less
| ||
 for Rocker, suitable for WME (Z7), eWME E8000 (Z4/Z5), eWME EP8 (Z10), Xyron Alu and Carbon BES2 (Z6) and BES3 (Z11) and Xyron LT / ST (Z20) Read more Read less
| ||
suitable for Xyron S 5.0, desert matt / plum matt, Mod. 25 (Z11) Read more Read less
| ||
 for chain stay, suitable for GRV Carbon, RR Carbon, Xyron Carbon, Smart system, BES3 (Z11) Read more Read less
| ||
 for Frame main bearing, suitable for Xyron aluminum and carbon with BES3 and smart system (Z11), Ryvon (Z18) and all Xyron LT / ST Read more Read less
|
The Conway "Xyron S 5.0 Carbon" is a high-quality full-suspension e-bike designed for demanding riders. With a total weight of 25.4 kg and a permissible total weight of 130 kg, it offers stability and robustness for a wide variety of terrains.Powered by a Bosch mid-motor with a battery capacity of 750 Wh, it provides support up to 25 km/h, making it easier to ride on long distances and steep climbs. 150 mm of suspension travel on the Suspension Fork and Frame ensures comfort and control on all trails. The 12-speed derailleur gear system from SRAM (model "SX Eagle") with a 1x 12-speed gear ratio enables precise gear changes. Hydraulic disc brakes provide reliable braking power. The MX concept, with a 29" Front Wheel and 27.5" Rear Wheel, also contributes significantly to the bike's handling and sporty appeal. The Conway "Xyron S 5.0 Carbon" combines innovative technology and sophisticated design for an outstanding riding experience.
