CONWAY Electric MTB hardtail "Cairon S 2.0 500" Mod. 24
trapeze, 29", shadowgrey metallic / desert matt, 9-speed TEKTRO "M350", 53 cm / XL
Read more Read less - Article number: 02825834
The electric MTB hardtail has an aluminum frame and is equipped with a Bosch Performance Line CX mid-motor that delivers 250 W of power. The frame houses a Battery with a capacity of 500.0 Wh. Drives are provided by a chain drive and gear selection is made possible by a 9-speed TEKTRO "M350" derailleur gear system. The Suspension Fork offers a suspension travel of 120 mm and the braking system consists of hydraulic Disc Brakes. The permissible system weight is 130 kg. The model also offers electronic Pushing Help.
PU 1
Product information
- Battery capacity 500.0 Wh
- Bosch Smart System yes
- Brake system hydraulic disc brake
- Chainstay 455 mm
- Colour designation shadowgrey metallic / desert matt
- Drive chain
- Drive system BOSCH Performance Line CX
- Drive version middle motor
- E-bike yes
- Engine power 250 W
- Features electronic sliding aid
- Frame height 53 cm
- Frame shape trapeze
- Frame size XL
- Gears 9-speed
- Gender ladies
- Main colour grey
- Material 1 aluminium
- Modellreihe Cairon
- Permissible system weight 130 kg
- Reach 468 mm
- Seat angle 74.5 °
- Seat tube 530 mm
- Secondary colour beige
- Shifting name 9-Gang TEKTRO "M350"
- Shifting type derailleur shifting
- Stack 658 mm
- Steering tube 130 mm
- Steering tube angle 67.0 °
- Stem length 90.0 mm
- Support up to 25km/h
- Toptube 640 mm
- Transmission 1x 9-speed
- Travel 120 mm
- Type hardtail
- Wheel distance 1220 mm
- Wheel size 29 "
- Battery: BOSCH "PowerTube 500", 500 Wh
- Battery Lock: AXA "New Lock"
- Bremse H.R.: TEKTRO Disc Brake "HD-M280", hydraulic, 2 pistons, for 1.8 mm brake rotors
- Chain / belt: SHIMANO "CN-HG53"
- Chain ring / pulley: MIRANDA, 36 teeth
- Charger: BOSCH 4 A
- Crank: MIRANDA "Classic", 165 mm, for Bosch Gen. 4, ISIS, Q:12, black
- Derailleur hanger: CONWAY "V2" for Cairon QR
- Display: BOSCH "Intuvia 100", 4-stages, remote control, push aid
- Engine: BOSCH "Performance Line CX", max. 85 Nm
- Fork: RST "Blaze ML", 120 mm travel, QR
- Frame: Intube Bosch, Gen. 4, BES3, aluminum, trapeze, 53 cm
- Front hub: SHIMANO "Tourney TX HB-TX505", Center Lock, QR
- Front rotor: TEKTRO "TR180-35", Ø 180 mm, Center Lock
- Front tire: SCHWALBE "Tough Tom", 60-622
- Grips: CONWAY "Sport", 130 mm, black
- Handlebar: LEVELNINE "Low Riser", 720 mm, Ø 31.8 mm, backsweep 9°, upsweep 5°
- Headset: GLORY WHEEL "SIT3 Strummer", ZS56/28.6 / ZS56/40
- Pedals: VP COMPONENTS "VPE-506"
- Rear derailleur: TEKTRO "RD-M350"
- Rear hub: SHIMANO "Tourney TX FH-TX505", Center Lock, QR
- Rear rotor: TEKTRO "TR180-35", Ø 180 mm, Center Lock
- Rear tire: SCHWALBE "Tough Tom", 60-622
- Remote: BOSCH "BRC3300", mini remote
- Rims: RODI "Ready 30", 30-584, 32 holes, disc brake, easy eyelets, black
- Saddle: Selle Royal "Vivo", Athletic
- Seatpost: CONWAY, Ø 31.6 mm, 350 mm long, 15 mm offset
- Sensor: Pedal pressure measuring im Motor + speed sensor
- Spokes: Niro, schwarz
- Stem: CONWAY, 1 1/8", 31,8mm handlebar clamp, 90mm long, angle 7°, black
- EAN: 4251971118676
- MSRP: €3,099.95
- WEEE registration number: DE92509320
- Fedas-Code: 154020
- Bidex-Code: 121010
- DST-Code: 1E01
- SB-Article: No
- Brand/Supplier CONWAY
- Unit of measure: PIECE
- Weight: 23.5 kg
| Article | Price | |
|---|---|---|
 grey 20/21, MS, GRV, Cairon T, Xyron Read more Read less
| PU 36 |
The "Cairon S 2.0 500" takes you off-road in a balanced and sporty manner! The entry-level model in the MTB range starts the new model year with a technology update. The bike is now equipped with the Bosch Smart System and is therefore fully networked and compatible with the E-Bike Flow app.The Battery is fully integrated into the down tube, making the bike particularly slim and tidy. The 4th generation Bosch "Performance CX" mid-motor is powered by the 500 Wh Battery. The Tektro derailleur takes care of the finer details of the drives.If you accelerate hard, you also need to brake precisely: the hydraulic Disc Brakes with their 180 mm disc diameter do this extremely reliably. The e-hardtail is suitable for trails and touring with the RST Suspension Fork, which provides a lot of compensation with its 120 mm. With its large 29er wheels, the "Cairon S 2.0 500" has already laid the foundation for bumpy trails. In combination with the chunky tread of the Schwalbe "Tough Tom" tires, the bike is designed for trails.
