CONWAY Electric trekking bike "Cairon T 500" Mod. 21

diamond, 28", black matt / blue, 12-speed SHIMANO "Deore", 58 cm / XL

Article number: 02887966
Original number: 21080483

This item is available in 12 variants. All in Spare parts All in Accessories

Product information

Battery capacity 625.0 Wh
Bosch Smart System no
Brake system hydraulic disc brake
Chainstay 450 mm
Colour designation black matt / blue
Drive chain drive
Drive system BOSCH Performance Line CX
Drive version middle motor
E-bike yes
Engine power 250 W
Features fender
Frame height 58 cm
Frame shape diamond
Frame size XL
Gears 12-speed
Gender gents
Main colour black
Material 1 aluminium
Permissible system weight 130 kg
Seat angle 73.0 °
Seat tube 580 mm
Secondary colour blue
Shifting name 12-Gang SHIMANO "Deore"
Shifting type derailleur shifting
Stack 651 mm
Steering tube 150 mm
Steering tube angle 71.0 °
Support up to 25km/h
Toptube 615 mm
Transmission 1x 12-speed
Travel 80 mm
Type trekking bike
Wheel distance 1122 mm
Wheel size 28 "

Battery: BOSCH "Powertube 625", Lithium-Ionen mit BMS, 625 Wh
Bottom bracket: BOSCH
Brake: TEKTRO "HD-T390"
Brake lever: TEKTRO "HD-T390"
Chain / belt: SHIMANO "CN-M6100"
Chain guard: Wave = HESLING "Move"
Chain ring / pulley: FSA "W0146 WB460 W1155", 38 Z.
Charger: Bosch 4 Ah
Crank: FSA "CK-745", 170 mm
Derailleur hanger: 0281167/7
Display: BOSCH, "Kiox", 4-Stufen, Remote Control, Schiebehilfe
Engine: BOSCH Mittelmotor Gen.4 "Performance CX", 36 V, 250 W
Fender: SKS, Kunststoff
Fork: ROCKSHOX "Recon Silver RL", 80 mm
Frame: CONWAY Intube Bosch, Alu
Frame Lock: AXA "Bock XXL"
Front hub: SHIMANO "HB-MT400", 15 x 110 mm
Front light: CONTEC "LED Aurora 100 E+ 40"
Front rotor: TEKTRO "TR180 2,3", 180 mm
Front tire: SCHWALBE "Energizer Active Plus", 50-622, Reflex
Grips: CONWAY "Sport"
Handlebar: ERGOTEC "Low Riser", Ø 31,8, 720 mm
Headset: ZS44 / ZS56
Pedals: VP "VPE-506"
Rear carrier: ATRAN "Cummute Pro", inkl. Federklappe
Rear derailleur: SHIMANO "Deore RD-M6100 Shadow Plus", 12speed
Rear hub: SHIMANO "FH-MT401" QR
Rear light: AXA "Blueline", LED
Rear rotor: TEKTRO "TR180 2,3", 180 mm
Rear tire: SCHWALBE "Energizer Active Plus", 50-622, Reflex
Rims: CONWAY Hohlkammer "X6", Disc
Saddle: SELLE ROYAL "Vivo Athletic Ergo", He
Seatpost: CONWAY Patent, 31,6 mm
Sensor: Pedal pressure measuring im Motor + speed sensor
Shifting lever: SHIMANO "Deore SL-M6100"
Spokes: Niro
Sprocket / pulley: SHIMANO "CS-M6100", 10-51 Z.
Stands: URSUS, Alu
Stem: ERGOTEC "Octopus", Adjustable

Supplier Article Number: 21080483
EAN: 4251507962261
MSRP: €3,799.95
WEEE registration number: DE92509320
DST-Code: 1B01
SB-Article: No
Bidex-Code: 122010
Fedas-Code: 155021
Brand/Supplier CONWAY
Unit of measure: PIECE
Weight: 26.8 kg
