CONWAY MTB full suspension "WME 5.9" Mod. 24
full suspension, 29", turquoise fade / red, 12-speed SHIMANO "XT" Mix, 50 cm / XL
Read more Read less - Article number: 02822930
- Original number: BK23HA0608
Das MTB Full-Suspension besitzt einen Carbonrahmen mit einem Rahmenfederweg von 150 mm. Die Federgabel hat einen Gabelfederweg von 150 mm. Der Antrieb erfolgt über eine Kette und die Gearauswahl wird durch eine 12-Gang SHIMANO "XT" Mix Kettenschaltung ermöglicht. An den Laufrädern sind hydraulische Scheibenbremsen installiert. Die Laufradgröße beträgt 29". Das zulässige Systemgewicht liegt bei 130 kg. Das MTB Full-Suspension ist mit Dämpfer ausgestattet.
Product information
- Brake system hydraulic disc brake
- Chainstay 440 mm
- Colour designation turquoise fade / red
- Drive chain
- E-bike no
- Features damper
- Frame height 50 cm
- Frame shape full suspension
- Frame size XL
- Frame travel 150 mm
- Gears 12-speed
- Gender gents
- Main colour blue
- Material 1 carbon
- Permissible system weight 130 kg
- Reach 487 mm
- Seat angle 75.0 °
- Seat tube 500 mm
- Secondary colour red
- Shifting name 12-Gang SHIMANO "XT" Mix
- Shifting type derailleur shifting
- Stack 631 mm
- Steering tube 125 mm
- Steering tube angle 65.0 °
- Stem length 40.0 mm
- Toptube 644 mm
- Transmission 1x 12-speed
- Travel 150 mm
- Type full suspension
- Wheel distance 1253 mm
- Wheel size 29 "
- Bottom bracket: SHIMANO "BB-MT500-PA", Pressfit BB92, 89.5 mm / 92 mm housing width
- Chain / belt: SHIMANO "Deore CN-M6100"
- Crankset: SHIMANO "FC-MT510", 170 mm, 30 teeth, 12-speed
- Damper: ROCKSHOX "Deluxe Select + RT", 230 x 57.5 mm
- Derailleur hanger: CONWAY für WME carbon, Xyron, RLC FS, Cairon SUV FS, from mod.20
- Fork: ROCKSHOX "Lyrik Select", 150 mm travel, DebonAir+, Charger RC, Maxle Ultimate Thru Axle
- Frame: Carbon, full suspension, 50 cm
- Front hub: FORMULA "DC-511", 15 x 110 mm, Thru Axle
- Front rotor: TRP "RS01E", Ø 203 mm, 6-hole, 2.3 mm thickness
- Front tire: SCHWALBE "Magic Marry", 62-622
- Grips: SQlab "70X"
- Handlebar: RACEFACE "Aeffect R", 780 mm, Ø 35 mm, Rise 20 mm
- Headset: ACROS ZS44/28.6 / ZS56/40
- Rear derailleur: SHIMANO "Deore XT RD-M8100"
- Rear hub: FORMULA "MST-148 S", 12 x 148 mm Boost, Thru Axle, 6-hole
- Rear rotor: TRP "RS01E", Ø 180 mm, 6-hole, 2.3 mm thick
- Rear tire: SCHWALBE "Big Betty ", 62-622
- Rims: RODI "Ready 30", 30-622, 32 holes, disc brake, easy eyelets, black
- Saddle: Selle Royal "2315HRN", Athletic
- Seatpost: CONTEC "Big Drop-A-Gogo", Ø 31.6 mm, 480 mm long, 170 mm adjustment range
- Spokes: Niro, schwarz
- Stem: RACEFACE "Aeffect R", 1 1/8", 35mm handlebar clamp, 40mm long, angle 0°, stack 39mm, black
- Supplier Article Number: BK23HA0608
- EAN: 4251971103573
- MSRP: €3,499.95
- Bidex-Code: 101020
- DST-Code: 1E00
- Fedas-Code: 154040
- SB-Article: No
- Brand/Supplier CONWAY
- Unit of measure: PIECE
- Weight: 15.3 kg
| Article | Price | |
|---|---|---|
 suitable for WME Carbon (Z7) Read more Read less
| ||
 | ||
 12-speed, right, with gear display Read more Read less
| ||
 | ||
 32 teeth, 170 mm crank length Read more Read less
| ||
 Press-in Bearing Shells, Pressfit Read more Read less
| ||
 suitable for WME(Z7) / RLC FS (Z8) / GRV carbon from 2019 Read more Read less
| ||
 | ||
 | ||
 WME 5.9, graphite fade / acid metallic and turquoise fade / redalso suitable for 8.9, graphite fade / gold matt Read more Read less
| ||
 | ||
 | ||
 suitable for SHIMANO 12-speed, Micro Spline system, 365g Read more Read less
| ||
 | ||
 | ||
 12 x 148mm, 180mm long, 1,75mm thread pitch, Boost Read more Read less
| ||
 Ø 31,6mm, 125mm adjustment range, 390mm long Read more Read less
| ||
 | ||
Ø 31,6mm, 100mm adjustment range, 340mm long Read more Read less
| ||
 | ||
 | ||
 10-12-14-16-18-21-24-28-33-39-45-51Teeth Read more Read less
| ||
 suitable for WME Carbon (Z7) and Xyron Carbon BES2 and BES3 (Z6 / Z11), for Xyron Alu the spacer 0.281.070/0 is also required Read more Read less
| ||
 | ||
 | ||
 Press-in Bearing Shells, Pressfit Read more Read less
| ||
 | ||
 for 1 x 12-speed, max. 51 teeth, SGS Read more Read less
| ||
 | ||
 | ||
 for WME 5.9 / 8.9 graphite fade / acid metallic And turquoise fade / redalso suitable for 8.9, graphite fade / gold matt Read more Read less
| ||
 suitable for WME (Z7), 180 mm / M12 x P1, 75 x 20 mm Read more Read less
| ||
 suitable for WME from 2020 (Z7) Read more Read less
| ||
 suitable for WME Carbon / Xyron Carbon Read more Read less
| ||
 | ||
 12-speed, right, without gear display Read more Read less
| ||
 suitable for all Xyron Carbon, WME (Z7), Ryvon (Z18), M12x1.0, shaft length 30.5 mm Read more Read less
|
Are you looking for a trail bike with a sporty, relaxed feel that will take you over hill and dale, through fields and meadows? CONWAY's "WME 5.9" is such a bike that shines with fine details. Technically new this year is the hydraulic disc brake "Slate Trail" from TRP, which reliably stops the bike downhill.The sporty, relaxed feel comes from the modern frame geometry with shorter reach, longer wheelbase and a flatter steering angle. The ROCKSHOX suspension with "Lyrik Select" fork and "Deluxe Select+" rear shock with 150mm travel make the full suspension bike really capable off-road. At the same time, the SCHWALBE tire mix of "Magic Mary" in the front and "Big Betty" in the rear in 62mm width provides the right grip. If it goes uphill, helps the proven 12-speed drive SHIMANO "XT" with wide range cassette with 10-51 teeth.The "Drop-A-Gogo" adjustable seatpost is one of the fine details by which you always sit in the most efficient position on your bike. As well as the externally covered bearing points, which are less susceptible to dust and mud, and incidentally provide a clean look.
