Required for the tightness test of radiator caps.

Required for the use of a cooling system tester.

with pressure gauge, flexible hose with quick connector and drain valve

For easy leak test checking of the of cooling systems and the function of the pressure relief valve on the radiator cap.

Instruction: checking the tightness of the cooler system
The adapters BS0244B and BS0244C are screwed onto the radiator opening instead of the original radiator cap using a bayonet lock. The hand pump is now connected to the adapter via the quick release.

Instruction: Check the function of the pressure relief valve on the radiator cap
The adapter BS0244F is connected to the hand pump via the quick release. Now connect the BS0244D or BS0244E connecting piece to the BS0244F adapter using a bayonet lock. The desired radiator cap can now be turned onto the open side of the BS0244D or BS0244E adapter.

Technical data:
cassette total dimensions (LxWxH): 200 x 300 x 85mm
measuring range: (0 - 2,5 bar / 0 - 36 psi)

The set contains following articles:
Hand pump: with pressure gauge, flexible hose with quick connector and drain valve (BS0244A), 0.577.351/0
connecting piece in black: R123 / R124 (BS0244D), 0.577.354/4
connecting piece in red: R123 / PA66 (BS0244E), 0.577.355/1
radiator cap dapter large: (BS0244F), 0.577.356/9
radiator cap adapter medium: small wings (BS0244C), 0.577.353/6
radiator cap adapter small: large wings (BS0244B), 0.577.352/8

Usage:
The check may only be carried out when the engine is switched off. Make sure that the coolant and the engine are cold so that no coolant can reach hot engine parts in the event of a leak.

Professional TPMS (tire pressure monitoring system) TMPS diagnostic and programming tool for motorcycle OE sensors, full range of functions also available for car OE sensors
Read out, activate, teach-in, program and clone ALCAR sensors, blind sensor detection, LCD color display, incl. 3-year software license. In addition to the device, a USB and OBD cable are included in the scope of delivery.
Operating instructions can be found under the media in the operating instructions.

Starter package consisting of 1x TECH350 (0.576.479/6) diagnostic devices and 4x TPMS sensors.

Professional TPMS (tire pressure monitoring system) TMPS diagnostic and programming tool for motorcycle OE sensors, full range of functions also available for car OE sensors.
Read out, activate, teach-in, program and clone ALCAR sensors, blind sensor detection, LCD Display, incl. 3-year software license. In addition to the device, a USB and OBD cable are included in the scope of delivery.

Universal freely programmable TPMS sensor in OE quality for motorcycles. With the help of a TPMS/ TMPS programming and diagnostic tool, the sensor can be programmed or, even better, a clone of the OE sensor can be created. It supports all OE functions.

motorcycle diagnosis, basic software Bike bookable
Simple solution to make a fully-fledged diagnostic device out of an existing PC (only on Windows-based systems / devices)
System requirements:
minimum: Windows XP SP3 / Hardware: 512 MB RAM, 2 GB hard disc space, USB, 2.0 Interface
recommended: Windows 7 or higher / Hardware: 1024 MB RAM, 4 GB hard disc space, USB, 2.0 Interface
Scope of delivery: PC VCI diagnostic module, USB stick for Software installation (plug and play), Bluetooth adapter (Notebook), USB cable mega macs PC, lanyard Hella Gutmann Solutions, Mousepad Pimp your PC, sticker set Pimp your PC

mobile handheld tester, wireless, motorcycle
Reads all control units and systems, helps with the localization of error causes incl. tips for connections and components and optional vendor-specific adapter for the connection of the VCI to the different interfaces in motorcycles, scooters, quads or trikes
Scope of delivery: mega macs 42 SE Bike (incl. battery pack), DT VCI (wireless communication mode), power supply and power cable, crocodile clamps (red and black), Bluetooth adapter (wireless communication with PC), USB cable (host and device), charging cable for cigarette lighter, quick start guide, user manual on DVD
Incl. manual
