CONWAY Electric trekking bike "Cairon T 2.0 500" Mod. 23
diamond, 28", shadowgrey metallic matt / red metallic, 9-speed TEKTRO "M350", 51 cm / M
Read more Read less - Article number: 02828762
Please note the different equipment and prices of the individual models!
Product information
- Battery capacity 500.0 Wh
- Bosch Smart System yes
- Brake system hydraulic disc brake
- Category trekking bike
- Chainstay 485 mm
- Colour designation shadowgrey metallic matt / red metallic
- Drive chain drive
- Drive system BOSCH Performance Line
- Drive version middle motor
- E-bike yes
- Engine power 250 W
- Features chain guard , electronic sliding aid , fender , frame lock , suspension fork , suspension seatpost
- Frame height 51 cm
- Frame shape diamond
- Frame size M
- Gears 9-speed
- Gender gents
- Main colour grey
- Material 1 aluminium
- Permissible system weight 130 kg
- Reach 409 mm
- Seat angle 73.0 °
- Seat tube 510 mm
- Secondary colour red
- Shifting name 9-Gang TEKTRO "M350"
- Shifting type derailleur shifting
- Stack 631 mm
- Steering tube 130 mm
- Steering tube angle 68.5 °
- Stem length 90.0 mm
- Support up to 25km/h
- Toptube 600 mm
- Transmission 1x 9-speed
- Travel 80 mm
- Wheel distance 1167 mm
- Wheel size 28 "
- Battery: BOSCH "PowerTube 500", 500 Wh
- Battery Lock: AXA "Block XXL"
- Bremse H.R.: SHIMANO Disc Brakes "BL-MT200 / BR-MT200", hydraulic, Adapter for 180 mm
- Chain / belt: SHIMANO "CN-HG53"
- Chain guard: HESLING “Move”
- Chain ring / pulley: MIRANDA "Gen3", 36 Z., w CG
- Charger: BOSCH 4 A
- Crank: MIRANDA "Classic Gen3", 165 mm
- Crankset: MIRANDA "Classic", 165 mm, 36 teeth
- Derailleur hanger: CONWAY "V2" for Cairon QR
- Display: BOSCH "Intuvia 100", 4-stages, remote control, push aid
- Engine: BOSCH "Performance Line" engine, max. 75 Nm
- Fender: SKS "A 60 S"
- Fork: RST "Blaze ML", 80 mm travel, QR
- Frame: Intube Bosch, Gen. 3, BES3, aluminum, diamond, 51 cm
- Frame Lock: AXA "Block XXL"
- Front hub: SHIMANO "Tourney TX HB-TX505", Center Lock, QR
- Front light: CONTEC "DLUX 50 E+", 50 lux
- Front rotor: SHIMANO "SM-RT30", Ø 180 mm, Center Lock
- Front tire: CONTINENTAL "Contact Cruiser", 50-622, Reflex
- Grips: CONWAY "Sport", 130 mm, black
- Handlebar: LEVELNINE "Low Riser", 720 mm, Ø 31.8 mm, backsweep 9°, upsweep 5°
- Headset: GLORY WHEEL "SIT3 Strummer", ZS56/28.6 / ZS56/40
- Pedals: UNION "SP-827"
- Rear carrier: atranvelo "Commute Pro"
- Rear derailleur: TEKTRO "RD-M350"
- Rear hub: SHIMANO "Tourney TX FH-TX505", Center Lock, QR
- Rear light: CONTEC "TL-335 E"
- Rear rotor: SHIMANO "SM-RT30", Ø 180 mm, Center Lock
- Rear tire: CONTINENTAL "Contact Cruiser", 50-622, Reflex
- Remote: BOSCH "BRC3300", mini remote
- Rims: RODI "Blackrock 25", 25-622, 32 holes disc brake, easy eyelets, black
- Saddle: Selle Royal "Vivo", Athletic
- Seatpost: CONWAY, Ø 31.6 mm, 350 mm long, 15 mm offset
- Sensor: Pedal pressure measuring im Motor + speed sensor
- Spokes: Niro schwarz
- Stands: URSUS "R81 - Wave Rear"
- Stem: LEVELNINE "Adjustable", 1 1/8", 31,8mm handlebar clamp, 90mm long, black
- EAN: 4251971119956
- MSRP: €2,999.95
- WEEE registration number: DE92509320
- DST-Code: 1B01
- SB-Article: No
- Bidex-Code: 122010
- Fedas-Code: 155021
- Brand/Supplier CONWAY
- Unit of measure: PIECE
- Weight: 27.8 kg
| Article | Price | |
|---|---|---|
 for Cairon BES3 (Z11 / Z12), Xyron BES3 aluminium and carbon (Z11), Cairon SUV FS BES3 (Z14) and Nyvon (Z17) Read more Read less
| ||
 | ||
 | ||
 carrier attachment 50mm, self-service package Read more Read less
| ||
 suitable for all Bosch chargers Read more Read less
| ||
 | ||
 | ||
 | ||
 | ||
 suitable for Cairon trapeze, gents and wave, Smart System, BES3 (Z11 / Z12) Read more Read less
| ||
 | ||
 suitable for Cairon with rear QR (Z12) and Cairon SUV FS (Z14), Smart system, BES3 Read more Read less
| ||
 suitable for Cairon trapeze and gents with rear QR, Smart system, BES3 (Z12) Read more Read less
| ||
 29", suitable for Cairon C from mod.20dimensions (HxW): 400 x 99mm Read more Read less
| ||
 32 hole, QR 173 mm, 135 mm installation width, black Read more Read less
| ||
 grey 20/21, MS, GRV, Cairon T, Xyron Read more Read less
| ||
 | ||
 | ||
 | ||
 Extensions for 500 Wh Battery to 625 Wh Battery Bracket and 625 Wh Battery to 750 Wh Battery Bracket Read more Read less
| ||
 | ||
 | ||
 | ||
 | ||
 suitable for Cairon Wave / Trapeze / Men (Z11 and Z12), Xyron Aluminum and Xyron Carbon / Aluminum, smart system, BES3 (Z11) and Xyron LT / ST (Z20) Read more Read less
| ||
 suitable for Cairon with rear QR axle (Z12), Gen.3 (Performance Line), Smart system (BES3) Read more Read less
| ||
 | ||
 | ||
 suitable for Cairon with rear QR axle (Z12) and Cairon SUV FS (Z14), Smart system, BES3 Read more Read less
| ||
 | ||
 | ||
 |
Whether on extended weekend tours or for errands through the city - our "Cairon T 2.0 500" is designed for versatile use. The Bosch "Performance" e-drive, providing powerful acceleration of up to 25 km/h. It is powered by the 500 Wh battery, which elegantly disappears in an aluminum down tube. The overall low center of gravity gives the pedelec a natural ride.Bosch Smart System creates a versatile e-bike with digital connectivity. Just download the E-Bike Flow app and you can connect your smartphone to your bike and always have all your tour data at your fingertips.The carrier takes on all the bags packed with spare clothes or provisions for tours. The mudguards, on the other hand, make the bike more suitable for use in the city. Dirt and splashing water are kept away sovereign.The drive supports the reliable derailleur and the hydraulic disc brakes - both from Tektro - for precise braking. The 50mm wide Continental tires in combination with the suspension fork and the suspension seatpost give the "Cairon T 2.0 500" a lot of comfort.
