CONWAY Electric trekking bike "Cairon TF 3.8" Mod. 24
wave, 28", darkblue metallic matt / platin matt, 8-speed SHIMANO "Nexus" freewheel, 50 cm / L
Read more Read less - Article number: 02896637
- Original number: 22080442
Product information
- Battery capacity 625.0 Wh
- Bosch Smart System no
- Brake system hydraulic disc brake
- Category trekking bike
- Chainstay 485 mm
- Colour designation darkblue metallic matt / platin matt
- Drive chain drive
- Drive version middle motor
- E-bike yes
- Engine power 250 W
- Features fender
- Frame height 50 cm
- Frame shape wave
- Frame size L
- Gears 8-speed
- Gender ladies
- Main colour blue
- Material 1 aluminium
- Reach 420 mm
- Seat angle 73.0 °
- Seat tube 500 mm
- Secondary colour silver
- Shifting name 8-Gang SHIMANO "Nexus" Leerlauf
- Shifting type internal gear shifting
- Stack 659 mm
- Steering tube 170 mm
- Steering tube angle 68.0 °
- Stem length 110.0 mm
- Support up to 25km/h
- Toptube 620 mm
- Transmission 1x 8-speed
- Travel 80 mm
- Wheel distance 1189 mm
- Wheel size 28 "
- Battery Lock: AXA "Block XXL", for PowerTube, BES2
- Bremse H.R.: TEKTRO Disc Brakes "HD-T280", hydraulic, 2 pistons, A11 Adapter, for 1.8 mm brake rotors
- Chain / belt: KMC "Z610 EPT"
- Chain guard: HESLING "Move", plastic, 38 teeth, black matt
- Derailleur hanger: CONWAY "Slider Hub" for Cairon from mod. 2020
- Display: BOSCH "Intuvia", 4 levels, remote control, push aid
- Fender: SKS "A 60 S", plastic, 60 mm, black
- Frame: Intube Bosch, Gen. 3, BES2, aluminum, Wave, 50 cm
- Frame Lock: AXA "Block XXL", for PowerTube, BES2
- Front light: CONTEC "DLUX 50 E+", 50 lux
- Front tire: CONTINENTAL "Contact Urban", 50-622, reflex
- Grips: HERRMANS "Clik Original DD37", 90/123 mm, handlebar clamps, black
- Handlebar: ERGOTEC "Lady Town", 620mm, Ø 31,8mm, 30° backsweep, rise 16mm, Level 4, black
- Pedals: UNION "SP-827"
- Rear carrier: ATRANVELO "Commute Pro", AVS system, F-Fix, black
- Rear derailleur: SHIMANO "Nexus SG-C6001", 8speed, LL
- Rear hub: SHIMANO "Nexus SG-C6001-8D", 8-speed, freewheel, Center Lock, 32 holes, black
- Rear light: CONTEC "TL-335 E-Stop", 50 mm screw spacing, stop light function
- Rear tire: CONTINENTAL "Contact Urban", 50-622, reflex
- Saddle: SELLE ROYAL "Vivo", ladies, moderate, black
- Seatpost: ERGOTEC "SP-10.0", Ø 31,6mm, 350mm long, 45mm travel, Level 5, black
- Sensor: Pedal pressure measuring im Motor + speed sensor
- Spokes: Niro, schwarz
- Sprocket / pulley: SHIMANO "SM-GEAR", 18 teeth
- Stands: URSUS "R81 - Wave Rear", adjustable, 40mm hole distance, matt black
- Stem: ERGOTEC "Octopus 2 Ahead 50",1 1/8", 31,8mm handlebar clamp, 110mm long, adjustable, Level 4, sandblasted black
- Supplier Article Number: 22080442
- EAN: 4251507982597
- MSRP: €3,399.95
- Brand/Supplier CONWAY
- Unit of measure: PIECE
- Weight: 29.2 kg
Article | Price | |
---|---|---|
![]() extension for 500 Wh battery to 625 Wh battery bracketMounting material must be ordered separately:2x 0.281.163/02x 0.281.163/2 Read more Read less
| ||
![]() Bosch Gen.3, suitable for Conway Cairon Read more Read less
| ||
![]() | ||
![]() 90mm long, sandblasted black, eff. length: 90 / 60mm, eff. height: 50 / 120mm Read more Read less
| ||
![]() for steering tube, suitable for Cairon gents, trapeze and wave and xyron with 500/625 Wh PT battery, BES2 (Z6) Read more Read less
| ||
![]() | ||
![]() 27,5"/28", suitable for Conway Cairon T Wave IGH from mod.20dimensions (HxW): 350 x 99mm Read more Read less
| ||
![]() | ||
![]() | ||
![]() suitable for Cairon Wave top (Z11, Z12) and Cairon SUV FS top (Z14), smart system, BES3 Read more Read less
| ||
![]() horizontalincl. mounting plate 0.299.931/6 Read more Read less
| ||
![]() suitable for Cairon and Xyron Aluminium BES2 (Z6) Read more Read less
| ||
![]() | ||
![]() suitable for all Bosch chargers Read more Read less
| ||
![]() suitable for Conway MS / MC / ML / MCL (27,5“ and 29“) and Cairon BES2 (Z6) with fork with 1 1/8“ shaft Read more Read less
| ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() 32 holes (special item, bulk) Read more Read less
| ||
![]() 21-622 (28"), rim height: 20,2mm Read more Read less
| ||
![]() | ||
![]() | ||
![]() | ||
![]() matt black, 38 teeth, suitable for Conway Cairon Read more Read less
| ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() suitable for Cairon and Xyron with BES2 system and PT battery (Z6 and Z9) Read more Read less
| ||
![]() | ||
![]() suitable for Cairon Wave (Z6, Z11, Z12) and Cairon Wave FS (Z9, Z14), smart system, BES3 Read more Read less
| ||
![]() | ||
![]() for down tube, suitable for Cairon gents, trapeze and wave und Xyron with 500 / 625 Wh PT battery, BES2 (Z6) Read more Read less
| ||
![]() suitable for Cairon / Cairon Wave / Cairon SUV FS and Xyron BES2 (Z6 and Z9) Read more Read less
| ||
![]() for Powertube charging base, black Read more Read less
| ||
![]() EPT, self-service package, 112 links Read more Read less
| ||
![]() 38 teeth, without chain guard ring Read more Read less
| ||
![]() suitable for Cairon, rubber, chain stay cable guide, except MTB gents + Trap. Powertube Read more Read less
| ||
![]() carrier attachment 50mm, self-service package Read more Read less
|
Article | Price | |
---|---|---|
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() moss / black, size XL Read more Read less
| ||
![]() | ||
![]() moss / black, size L Read more Read less
| ||
![]() | ||
![]() grey / black, size XXL Read more Read less
| ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() moss / black, size XS Read more Read less
| ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() grey melange with silver sticker Read more Read less
| ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() moss / black, size S Read more Read less
| ||
![]() | ||
![]() | ||
![]() | ||
![]() grey / black, size XL Read more Read less
| ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() moss / black, size M Read more Read less
| ||
![]() moss / black, size XXL Read more Read less
| ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() grey / black, size M Read more Read less
| ||
![]() | ||
![]() | ||
![]() grey / black, size L Read more Read less
| ||
![]() grey / black, size XS Read more Read less
| ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() | ||
![]() grey / black, size S Read more Read less
| ||
![]() |
The "Cairon TF 3.8" is designed for active riding comfort. The wave model made of aluminum is powered by the powerful, but always natural-looking, BOSCH "Active Line Plus" motor. The low center of gravity at the bottom bracket also adds to the natural feel. This way, the bike can be maneuvered nimbly over cobblestones or forest paths.You will appreciate the suspension seatpost, especially on cobblestones or dirt roads. It levels out the bumps in interaction with the suspension fork. The robust CONTINENTAL "Contact Urban" tires, which cushion well in 50 mm width, also contribute to this. With reflective stripes, they also offer even more safety in road traffic.In addition to the four motor support levels, the SHIMANO "Nexus" 8-speed hub gears with freewheel also contribute to the correct gear ratio and pleasant cadence. The hydraulic disc brakes, on the other hand, ensure abrupt stops when necessary. However, they can also always be precisely dosed on long descents.The natural riding feel means that tours can well and truly be extended into the evening hours. Snacks and a bottle of wine for a sundowner at the lake can be carried on the rear rack. The CONTEC LED light safely illuminates the way home, where you can simply remove the battery from the down tube for recharging. The next trip with the "Cairon TF 3.8" can start!
