CONWAY MTB RTLR (StVZO) "Razz C 4.0" (#1)
hardtail, 29", black metallic, 24-speed SHIMANO "Acera", 41 cm / S
Read more Read less - Article number: 02810607
- Original number: 4251971171923
Das Fahrrad hat einen Aluminiumrahmen. Es besitzt eine Federgabel mit einem Gabelfederweg von 100 mm. Der Antrieb erfolgt über eine Kette. Das Fahrrad ist ausgestattet mit einer 24-Gang SHIMANO "Acera" Kettenschaltung und einer hydraulischen Scheibenbremse. Das zulässige Gesamtgewicht beträgt 130 kg.
Product information
- Brake system hydraulic disc brake
- Category hardtail
- Chainstay 448 mm
- Colour designation black metallic
- Drive chain drive
- E-bike no
- Features suspension fork
- Frame height 41 cm
- Frame shape hardtail
- Frame size S
- Gears 24-speed
- Gender gents
- Main colour black
- Material 1 aluminium
- Reach 369 mm
- Seat angle 72.4 °
- Seat tube 406 mm
- Shifting name 24-Gang SHIMANO "Acera"
- Shifting type derailleur shifting
- Stack 634 mm
- Standover height 771 mm
- Steering tube 120 mm
- Steering tube angle 70.0 °
- Stem length 70.0 mm
- Toptube 570 mm
- Transmission 3x 8-speed
- Travel 100 mm
- Wheel distance 1069 mm
- Wheel size 29 "
- Brake: TEKTRO "HD-M280"
- Brake lever: TEKTRO "HD-M280"
- Bremse H.R.: TEKTRO Disc Brake "HD-M275", hydraulic, 2 pistons, for 1.8 mm brake rotors
- Chain / belt: KMC "Z8", 8-speed
- Derailleur hanger: CONWAY for MS / MC / ML 27.5", 29" from 2019 model onwards
- Dynamo: SHIMANO "DH-3D37-QR", Center Lock, 32 hole, black
- Fender: SKS "Velo 65 Mountain", plastic, 65 mm, black
- Frame: Aluminum, diamond, 41 cm
- Front hub: SHIMANO "DH-3D37-QR", Center Lock, 32 hole, black
- Front light: HERRMANS "H-Black MR4 Dynamo", parking light
- Front rotor: TEKTRO "TR160-35", Ø 160mm, Center Lock, thickness: 1,8mm
- Front tire: IMPAC "Smartpac", 54-622, TwinSkin, 24 TPI, Reflex
- Grips: CONWAY "Sport", 130 mm, black
- Handlebar: LEVELNINE handlebar, 720mm, aluminium, Ø 31,8mm, rise 0,5mm, black
- Pedals: WELLGO "C280DU"
- Rear derailleur: SHIMANO "Acera RD-M360"
- Rear hub: SHIMANO "FH-TY505", Center Lock, 7-fach HG, 32 holes, QR, black
- Rear light: HERRMANS "H-Trace Mini Dynamo", parking light
- Rear rotor: TEKTRO "TR160-35", Ø 160mm, Center Lock, thickness: 1,8mm
- Rear tire: IMPAC "Smartpac", 54-622, TwinSkin, 24 TPI, Reflex
- Saddle: SELLE ROYAL "Vivo", men's, Athletic, black
- Seatpost: CONWAY, Ø 31.6 mm, 300 mm long, black
- Spokes: Steel black
- Stands: URSUS "R90 - Mooi Rear", adjustable, 40 mm hole spacing, black matt
- Stem: CONWAY, 1 1/8", 31,8mm handlebar clamp, 70mm long, angle 7°, black
- Supplier Article Number: 4251971171923
- EAN: 4251971171923
- MSRP: €699.95
- Bidex-Code: 101010
- DST-Code: 1E00
- Brand/Supplier CONWAY
- Unit of measure: PIECE
| Article | Price | |
|---|---|---|
 11-13-15-17-20-23-26-34 teeth Read more Read less
| ||
 70mm long, 31,8mm handlebar clamp Read more Read less
| ||
 | ||
 | ||
 | ||
 160 mm, old packaging Read more Read less
| ||
 | ||
 | ||
 | ||
 silver, self-service package, 114 links Read more Read less
| ||
 suitable for Conway MS / MC / ML / MCL (27,5“ and 29“) and Cairon BES2 (Z6) with fork with 1 1/8“ shaft Read more Read less
| ||
 | ||
 | ||
 EPT, self-service package, 114 links Read more Read less
| ||
 | ||
 | ||
 | ||
 | ||
 MS / MC / ML 27,5" / 29" from mod.19 Read more Read less
| ||
 122,5mm axle length, 68mm housing width Read more Read less
| ||
 | ||
 silver / gray, SB-packed, 122 links Read more Read less
| ||
 | ||
 720mm long, Ø 31,8mm, 9° backsweep, 5° upsweep, rise: 15mm Read more Read less
| ||
 23-622, 609 mm ERD (measured incl. spoke holes), 16.2 mm high, 23.2 mm inner width, 28.3 mm outer width, approx. 566 g Read more Read less
|
Off you go with your new "Razz C 4.0" from Conway to school, to sports or on the trails - this hardtail youth bike is ready for anything! As a fully equipped version, it offers you the perfect mix of suitability for everyday use and a thirst for adventure.The robust aluminum frame and the RST "Gila ML" fork with 100 mm suspension travel ensure stability and comfort on any terrain. The 24-speed "Acera" derailleur gears from Shimano allow you to change gears quickly and precisely, while the hydraulic disc brakes from Tektro offer you maximum control and safety.The IMPAC "Smart Pac" tires with reflective strips give you good grip and increased visibility in traffic. The CONWAY riser handlebars and the Selle Royal "Vivo Athletic Ergo" saddle ensure a comfortable and ergonomic riding position for a lot of time on the bike.
