CONWAY MTB RTLR (StVZO) "Razz C 4.0" (#1)
hardtail, 29", black metallic, 24-speed SHIMANO "Acera", 56 cm / XL
Read more Read less - Article number: 02810610
- Original number: 4251971171954
Das Fahrrad hat einen Aluminiumrahmen. Es besitzt eine Federgabel mit einem Gabelfederweg von 100 mm. Der Antrieb erfolgt über eine Kette. Das Fahrrad ist ausgestattet mit einer 24-Gang SHIMANO "Acera" Kettenschaltung und einer hydraulischen Scheibenbremse. Das zulässige Gesamtgewicht beträgt 130 kg.
Product information
- Brake system hydraulic disc brake
- Category hardtail
- Chainstay 448 mm
- Colour designation black metallic
- Drive chain drive
- E-bike no
- Features suspension fork
- Frame height 56 cm
- Frame shape hardtail
- Frame size XL
- Gears 24-speed
- Gender gents
- Main colour black
- Material 1 aluminium
- Permissible system weight 130 kg
- Reach 423 mm
- Seat angle 72.4 °
- Seat tube 559 mm
- Shifting name 24-Gang SHIMANO "Acera"
- Shifting type derailleur shifting
- Stack 652 mm
- Standover height 865 mm
- Steering tube 140 mm
- Steering tube angle 70.0 °
- Stem length 110.0 mm
- Toptube 630 mm
- Transmission 3x 8-speed
- Travel 100 mm
- Wheel distance 1124 mm
- Wheel size 29 "
- Bottom bracket: SHIMANO "BB-UN101", BSA, 68 mm / 70 mm housing width
- Brake: TEKTRO "HD-M280"
- Brake lever: TEKTRO "HD-M280"
- Bremse H.R.: TEKTRO Disc Brake "HD-M275", hydraulic, 2 pistons, for 1.8 mm brake rotors
- Chain / belt: KMC "Z8", 8-speed
- Crankset: SHIMANO "Tourney FC-TY301", 175 mm, 24/34/42 teeth
- Derailleur hanger: CONWAY for MS / MC / ML 27.5", 29" from 2019 model onwards
- Dynamo: SHIMANO "DH-3D37-QR"
- Fender: SKS "Velo 65 Mountain"
- Fork: RST "Gila", 100 mm travel, QR
- Frame: Aluminum, diamond, 56 cm
- Front derailleur: SHIMANO "Altus FD-M313", Down Swing
- Front hub: SHIMANO "DH-3D37-QR"
- Front light: HERRMANS "H-Black MR4 Dynamo"
- Front rotor: TEKTRO "TR160-35", Ø 160 mm, Center Lock
- Front tire: IMPAC "Smartpac", 54-622, Reflex
- Grips: CONWAY "Sport", 130 mm, black
- Handlebar: LEVELNINE Handlebar, 720 mm, Ø 31.8 mm, Rise 0.5 mm
- Headset: FSA "Orbit 1.5B ZS", ZS44/28.6 / ZS56/40, reduction cone
- Pedals: WELLGO "C280DU"
- Rear derailleur: SHIMANO "Acera RD-M360"
- Rear hub: SHIMANO "FH-TY505", Center Lock, QR
- Rear light: HERRMANS "H-Trace Mini Dynamo"
- Rear rotor: TEKTRO "TR160-35", Ø 160 mm, Center Lock
- Rear tire: IMPAC "Smartpac", 54-622, Reflex
- Rims: CONWAY "35 Bar", 32 hole
- Saddle: Selle Royal "Vivo", Athletic
- Seatpost: CONWAY, Ø 31.6 mm, 350 mm long
- Spokes: Steel black
- Stands: URSUS "R90 - Mooi Rear"
- Stem: CONWAY, 1 1/8", 31,8mm handlebar clamp, 110mm long, angle 7°, black
- Supplier Article Number: 4251971171954
- EAN: 4251971171954
- MSRP: €699.95
- Bidex-Code: 101010
- DST-Code: 1E00
- SB-Article: No
- Fedas-Code: 154010
- Brand/Supplier CONWAY
- Unit of measure: PIECE
| Article | Price | |
|---|---|---|
 | ||
 | ||
 | ||
 EPT, self-service package, 114 links Read more Read less
| ||
 | ||
 122,5mm axle length, 68mm housing width Read more Read less
| ||
 | ||
 suitable for Conway MS / MC / ML / MCL (27,5“ and 29“) and Cairon BES2 (Z6) with fork with 1 1/8“ shaft Read more Read less
| ||
 | ||
 MS / MC / ML 27,5" / 29" from mod.19 Read more Read less
| ||
 160 mm, old packaging Read more Read less
| ||
 | ||
 110mm long, 31,8mm handlebar clamp Read more Read less
| ||
 | ||
 | ||
 | ||
 11-13-15-17-20-23-26-34 teeth Read more Read less
| ||
 | ||
 720mm long, Ø 31,8mm, 9° backsweep, 5° upsweep, rise: 15mm Read more Read less
| ||
 silver / gray, SB-packed, 122 links Read more Read less
| ||
 | ||
 23-622, 609 mm ERD (measured incl. spoke holes), 16.2 mm high, 23.2 mm inner width, 28.3 mm outer width, approx. 566 g Read more Read less
| ||
 silver, self-service package, 114 links Read more Read less
| ||
 | ||
 |
Off you go with your new "Razz C 4.0" from Conway to school, to sports or on the trails - this hardtail youth bike is ready for anything! As a fully equipped version, it offers you the perfect mix of suitability for everyday use and a thirst for adventure.The robust aluminum frame and the RST "Gila ML" fork with 100 mm suspension travel ensure stability and comfort on any terrain. The 24-speed "Acera" derailleur gears from Shimano allow you to change gears quickly and precisely, while the hydraulic disc brakes from Tektro offer you maximum control and safety.The IMPAC "Smart Pac" tires with reflective strips give you good grip and increased visibility in traffic. The CONWAY riser handlebars and the Selle Royal "Vivo Athletic Ergo" saddle ensure a comfortable and ergonomic riding position for a lot of time on the bike.
